| Product properties | Product type: Data cable preassembled Sensor type: Ethernet Number of positions: 4 |
| Electrical properties | Attenuation: typ. 0.2 dB max. 0.6 dB Transmission medium: Multi-mode fiberglass |
| Mechanical properties | Tensile strength short-term/long-term: 800 N |
| Material specifications | Flammability rating according to UL 94: V0 Outer sheath, material: TPU |
| Connector | Connection 1 Handle color: black Insertion/withdrawal cycles: 1000 Degree of protection: IP68 (IEC 60529) IP68 Ambient temperature (operation): -40°C ... 85°C (IEC 61300-2-22) Number of positions: 4 Locking type: Screw locking mechanism Connection 2 Handle color: black Insertion/withdrawal cycles: 1000 Ambient temperature (operation): -40°C ... 85°C (IEC 61300-2-22) Number of positions: 4 Degree of protection: IP68 (IEC 60529) Locking type: Screw locking mechanism |
| Cable/line | Cable length: 35 m Cable weight: 26.00 kg/km Cable type: Multimode fiberglass Zip cord, fiberglass Outer sheath, material: TPU External sheath, color: black Individual wire diameter: 250 õm Tensile strength short-term/long-term: 800 N Halogen-free: complying with IEC 60754-1/2 FO cable Number of fibers: 12 Fiber: 62.5/125Ãõm OM1 Fiber type: Multimode fiberglass 62.5/125Ãõm Transmission medium: Multi-mode fiberglass |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP68 Ambient temperature (operation): -40°C ... 85°C (IEC 61300-2-22) Shock: 100g, according to IEC 61300-2-9 |
