| Product properties | Type: RJ45 Product type: Data connector (cable side) Sensor type: Ethernet/PROFINET Number of positions: 8 Connection profile: RJ45 No. of cable outlets: 1 Shielded: yes Cable outlet: angled Positions/contacts: 8P8C Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/3): 72 V (DC) Rated current: 1.75 A Contact resistance: < 20 mé (Contact) < 100 mé (shield) > 10 mé (Wire ââ¬Ã¢ IDC) 0.005 é (Litz wires ââ¬Ã¢ IDC) Frequency range: to 100 MHz Insulation resistance: > 500 Mé Nominal voltage UN: 48 V Nominal current IN: 1.75 A Contact resistance per contact pair: < 20 é Transmission medium: Copper Transmission characteristics (category): CAT5 Transmission speed: 1 Gbps Power transmission: PoE++ |
| Connection data | Connection technology Connection method: Insulation displacement connection Connection cross section AWG: 23 ... 22 (solid) 23 ... 22 (flexible) Conductor cross section: 0.25 mm² ... 0.34 mm² (solid) 0.25 mm² ... 0.34 mm² (flexible) Connection in acc. with standard: In accordance with IEC 60603-7-1 |
| Dimensions | Width: 13.6 mm Height: 41.2 mm Length: 37.9 mm |
| Material specifications | Material: Plastic Flammability rating according to UL 94: V0 Housing surface material: Ni Cable seal material: NBR Contact material: CuSn Contact surface material: Au/Ni Contact carrier material: PC Locking latch material: Stainless steel Housing material: Metal |
| Cable/line | External cable diameter (): 5 mm ... 9 mm External cable diameter: 5 mm ... 9 mm Wire diameter including insulation: ââ°¤ 1.6 mm Test voltage Core/Core: 1000 V Test voltage Core/Shield: 1500 V |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 750 Insertion force per signal contact: < 20.00 N Extraction force per signal contact: < 20 N |
| Environmental and real-life conditions | Test specification Type of test: Vibration test Specification: IEC 60068-2-6 Frequency: 10-500 Hz Sweep speed: 1Ãoctave/min Amplitude: 0.35 mm Acceleration: 50 m/s² Test duration: 20 s Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 70°C Ambient temperature (storage/transport): -40°C ... 70°C |
| Mounting | Mounting type: For field assembly Connection method: Insulation displacement connection |
