1422415 PHOENIX CONTACT -

SAC-5P-100,0-92X - Bus system cable

By the meter, Bus system cable, CANopen^®, DeviceNetÃ¢â¢, shielded, FRNC halogen-free, black, 4-wire (2xAWG24/19+2xAWG22/19), color single wire: red-black, blue-white, cable length: 100 m, for outdoor applications

Cod. Articolo: 1422415 copia - copy

Cod. Fornitore: 1422415 copia - copy

PHOENIX CONTACT

Product properties	Product type: Data cable by the meter Sensor type: CANopen^Ã® Number of positions: 4 Shielded: yes
Electrical properties	Transmission medium: Copper
Interfaces	Bus system: CANopen^Ã®/DeviceNetÃ¢Ã¢¢ Signal type/category: CANopen^Ã® DeviceNetÃ¢Ã¢¢
Cable/line	Cable length: 100 m CANopen Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/1e68ea1d8c29454c8e7e36d658f91c6e/-S204x204-FJPG Cable weight: 70 kg/km UL AWM Style: 21281 (80°C/300 V) Number of positions: 4 Shielded: yes Cable type: CANopen^Ã®/DeviceNetÃ¢Ã¢¢ outdoor installation, FRNC, blackÃ[92X] Conductor structure: 2xAWG24/19+2xAWG22/19 Signal runtime: 4.46 ns/m Conductor structure signal line: 19x 0.13 mm AWG signal line: 24 Conductor cross section: 2x 0.25 mm² (Signal) 2x 0.34 mm² (Power) 1x 0.38 mm² (Drain wire) Wire diameter incl. insulation: 1.9 mm (Signal) 1.4 mm (Power) External cable diameter: 6.9 mm Ã±0.3Ãmm Outer sheath, material: FRNC External sheath, color: black Conductor material: Tin-plated Cu litz wires Material wire insulation: PE Single wire, color: red-black, blue-white Thickness, insulation: 0.6 mm (Signal) 0.3 mm (Power) Thickness, outer sheath: 1.15 mm Twisted pairs: 2 cores to the pair Type of pair shielding: Aluminum-lined foil Overall twist: 2 pairs around a drain wire in the center to the core Optical shield covering: 70 % Max. conductor resistance: 90 Ã©/km (Signal) 55 Ã©/km (Power) Insulation resistance: Ã¢Ã¢°¥ 200 MÃ©*km (at 20Ã°C) Wave impedance: 120 Ã© Ã±12ÃÃ© (f = 1 MHz) Working capacitance: 39.8 nF (at 1 kHz, core/core) Nominal voltage, cable: Ã¢Ã¢°¤ 300 V Test voltage Core/Core: 2000 V (50ÃHz, 1Ãmin.) Test voltage Core/Shield: 2000 V (50ÃHz, 1Ãmin.) Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Halogen-free: yes Flame resistance: According to IEC 60332-3-25 (Cat. D) Resistance to oil: yes Other resistance: UV resistant Ambient temperature (operation): -40°C ... 105°C Ambient temperature (installation): -40°C ... 105°C
