Non disponibile
| Product properties | Product type: Sensor/actuator cable Number of positions: 12 No. of cable outlets: 1 Shielded: yes Coding: A Data management status Article revision: 05 Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: V0 Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: PA 6.6 Material for screw connection: Zinc die-cast, nickel-plated |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 30 V AC 30 V DC Nominal current IN: 1.5 A |
| Signaling | Status display: no Status display present: No |
| Connector | Connection 1 Type: Plug straight M12 SPEEDCON Number of positions: 12 Locking type: SPEEDCON Coding type: A Connection 2 Type: Socket straight M12 SPEEDCON Number of positions: 12 Locking type: SPEEDCON Coding type: A |
| Cable/line | Cable length: 6 m Black PUR/PVC twisted pair [35T] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9266/full/b1500?format=jpg Cable weight: 87 kg/km UL AWM Style: 20233 / 1061 (80 °C/300 V) Number of positions: 12 Shielded: yes Cable type: Black PUR/PVC twisted pair [35T] Conductor structure signal line: 18x 0.10 mm AWG signal line: 26 Conductor cross section: 12x 0.14 mm² (Signal line) Wire diameter incl. insulation: 1 mm ñ0.05 mm (Signal line) External cable diameter: 8.50 mm ñ0.2 mm Outer sheath, material: PUR External sheath, color: black RAL 9005 Conductor material: Tin-plated Cu litz wires Material wire insulation: PVC Single wire, color: white-brown, green-yellow, gray-pink, blue-red, black-violet, gray/pink-red/blue Twisted pairs: 2 cores to the pair Overall twist: Six pairs around the filler to the core Optical shield covering: 85 % Max. conductor resistance: ââ°¤ 142 é/km (at 20 °C) Insulation resistance: ââ°¥ 10 Mé*km (at 20 °C) Nominal voltage, cable: 42 V AC Test voltage: 1500 V AC Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Smallest bending radius, fixed installation: 43 mm Smallest bending radius, movable installation: 85 mm Dynamic load capacity (bending): Max. bending cycles: 2000000, Bending radius: 85 mm, Traversing path: 10 m, Traversing rate: 3 m/s, Acceleration: 10 m/s² Flame resistance: According to DIN EN 60332-1-2 According to VW-1 Resistance to oil: in accordance with DIN EN 60811-2-1 Other resistance: hydrolysis and microbe resistant (in accordance with EN 50396) Special properties: Flexible cable conduit capable Ambient temperature (operation): -40 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP68 Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) -40 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation) |
| Standards and regulations | Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 |
