1436055 PHOENIX CONTACT -

SAC-5PY-F/2X 5,0-920-MS-FS - Bus system cable

Bus system cable, CANopen^®, DeviceNetÃ¢â¢, 5-position halogen-free, shielded, Socket straight M12, coding: A SPEEDCON, on Socket straight M12, coding: A SPEEDCON and Plug straight M12, coding: A SPEEDCON, cable length: 5 m, all connectors unshielded, Shield connected to pin 1

Cod. Articolo: 1436055 copia - copy

Cod. Fornitore: 1436055 copia - copy

PHOENIX CONTACT

Product properties	Product type: Data cable preassembled Sensor type: CANopen^Ã® Number of positions: 5 Application: Standard No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3
Interfaces	Bus system: CANopen^Ã®/DeviceNetÃ¢Ã¢¢ Signal type/category: CANopen^Ã® DeviceNetÃ¢Ã¢¢
Signaling	Status display: No Status display present: No
Electrical properties	Contact resistance: Ã¢Ã¢°¤ 5 mÃ© Insulation resistance: Ã¢Ã¢°¥ 100 MÃ© Nominal voltage U_N: 48 VÃAC 60 VÃDC Nominal current I_N: 4 A Transmission medium: Copper
Material specifications	Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Zinc die-cast, nickel-plated
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/2fcc936e7f1dd647a08d20113593a631/-S204x204-FJPG Center distance: 21 mm
Connection data	Pin assignment Contact \| Color (signal designation) \| Contact (optional): 1 (Distributor) \| SR (shield) \| 1 (Plug)\| 1 (Socket) 2 (Distributor) \| RD (V+) \| 2 (Plug)\| 2 (Socket) 3 (Distributor) \| BK (V-) \| 3 (Plug)\| 3 (Socket) 4 (Distributor) \| WH (CAN_H) \| 4 (Plug)\| 4 (Socket) 5 (Distributor) \| BU (CAN_L) \| 5 (Plug)\| 5 (Socket)
Connector	Connection 1 Type: Socket straight M12 SPEEDCON Number of positions: 5 Coding type: A (Standard) Ambient temperature (operation): -25°C ... 90°C Locking type: SPEEDCON Connection 2 Type: Socket straight M12 SPEEDCON Number of positions: 5 Coding type: A (Standard) Ambient temperature (operation): -25°C ... 90°C Locking type: SPEEDCON
Cable/line	Cable length: 5 m CANopen Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/fc78069afd463243880387c2e14a096e/-S204x204-FJPG Cable weight: 90 kg/km UL AWM Style: 21198 (80°C/300 V) Number of positions: 4 Shielded: yes Cable type: CANopen^Ã®/DeviceNetÃ¢Ã¢¢, PUR, violetÃ[920] Conductor structure: 2xAWG24/19+2xAWG22/19 Conductor structure signal line: 19x 0.13 mm AWG signal line: 24 Conductor cross section: 2x 0.25 mm² (Data cable) 2x 0.34 mm² (Power supply) 1x 0.34 mm² (Drain wire) Wire diameter incl. insulation: 1.95 mm Ã±0.05 mm (Data cable) 1.4 mm Ã±0.05 mm (Power supply) External cable diameter: 6.7 mm Ã±0.3Ãmm Outer sheath, material: PUR External sheath, color: red lilac RAL 4001 Conductor material: Tin-plated Cu litz wires Material wire insulation: Foamed PE (Data cable) PE (Power supply) Single wire, color: red-black, blue-white Twisted pairs: 2 cores to the pair Type of pair shielding: Plastic-coated aluminum foil, aluminum side outside Overall twist: 2 pairs around a drain wire in the center to the core Optical shield covering: 80 % Insulation resistance: Ã¢Ã¢°¥ 5 GÃ©km (Data cable) Ã¢Ã¢°¥ 5 GÃ©km (Power supply) Loop resistance: Ã¢Ã¢°¤ 181.80 Ã©/km (Data cable) Ã¢Ã¢°¤ 114.80 Ã©/km (Power supply) Wave impedance: 120 Ã© Ã±10Ã% (with 1 MHz) Cable capacity: nom. 40 nF/km (Data cable) Nominal voltage, cable: Ã¢Ã¢°¤ 300 V (Peak value, not for high-power applications) Test voltage Core/Core: 2000 V (50ÃHz, 1Ãmin.) Test voltage Core/Shield: 2000 V (50ÃHz, 1Ãmin.) Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Smallest bending radius, fixed installation: 34 mm Smallest bending radius, movable installation: 67 mm Max. bending cycles: 5000000 Shield attenuation: Ã¢Ã¢°¤ 22.9 dB/km (with 1 MHz) Ã¢Ã¢°¤ 16.4 dB/km (At 500 kHz) Ã¢Ã¢°¤ 9.5 dB/km (At 125 kHz) Halogen-free: in accordance with DINÃVDEÃ0472 partÃ815 according to IEC 60754-1 Flame resistance: IEC 60332-1-2 in accordance with ISOÃ6722-1 5.22 (UN ECE-R 118.01) Other resistance: Low adhesion Ambient temperature (operation): -40°C ... 80°C (cable, fixed installation) -30°C ... 70°C (Cable, flexible installation) -20°C ... 60°C (for installation) -20°C ... 60°C (cable, drag chain applications)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 IP67
Standards and regulations	Standard designation: M12 connector Standards/specifications: IEC 61076-2-101
