| Notes | General: The electrical and mechanical data specified assume that the connector pair is correctly locked and mounted. If the connector is unlocked and if there is a danger of contamination, the connector must be sealed using a protective cap > IP54. Influences arising from litz wires, cables or PCB assembly must also be taken into consideration. |
| Product properties | Product type: Panel mounting base Thread type: M12 |
| Material specifications | Material for screw connection: Brass, nickel-plated |
| Connector | Connection 1 Head design: Pin Head thread type: M12 Head locking type: Push-Pull |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 100 |
| Environmental and real-life conditions | Ambient conditions Degree of protection (when plugged in): IP65/IP67 (correctly plugged in and locked) Degree of protection: IP65/IP67 (correctly plugged in and locked) IP67, when in locked state IP65, when in locked state Ambient temperature (operation): -25°C ... 85°C (Plug / socket) -40°C ... 85°C (without mechanical actuation) |
| Standards and regulations | M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-010 Note: In line with |
| Mounting | Mounting type: Front mounting Press-in mounting Assembly instructions: Press-in mounting Connection method: THR solder connection |
