| Product properties | Product type: Sensor/actuator cable Application: Standard Number of positions: 8 No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Zinc die-cast, nickel-plated |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 30 V AC 30 V DC Nominal current IN: 2 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Signaling | Status display: no Status display present: No |
| Connector | Connection 1 Type: free cable end Connection 2 Type: Socket angled M12 Number of positions: 8 Coding type: A |
| Cable/line | Cable length: 50 m PUR halogen-free black [PUR] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9112/full/b1500?format=jpg Cable weight: 46 kg/km UL AWM Style: 20549 / 10493 (80 °C/300 V) Number of positions: 8 Shielded: no Cable type: PUR halogen-free black [PUR] Conductor structure signal line: 32x 0.10 mm AWG signal line: 24 Conductor cross section: 8x 0.25 mm² (Signal line) Wire diameter incl. insulation: 1.17 mm ñ0.02 mm External cable diameter: 5.90 mm ñ0.15 mm Outer sheath, material: PUR External sheath, color: black-gray RAL 7021 Conductor material: Bare Cu litz wires Material, filler: PE Material wire insulation: PP Single wire, color: white, brown, green, yellow, gray, pink, blue, red Thickness, insulation: ââ°¥ 0.21 mm Thickness, outer sheath: approx. 0.80 mm Overall twist: 8 wires around filler to the core Max. conductor resistance: ââ°¤ 78 é/km Insulation resistance: ââ°¥ 1 Gé*km Wave impedance: 100 é +15 % (with 1 MHz) Cable capacity: ââ°¤ 70 pF/m Nominal voltage, cable: ââ°¤ 300 V Test voltage: ââ°¥ 3000 V Minimum bending radius, fixed installation: 8 x D Minimum bending radius, flexible installation: 10 x D Smallest bending radius, fixed installation: 48 mm Smallest bending radius, movable installation: 59 mm Dynamic load capacity (bending): Max. bending cycles: 4000000, Bending radius: 59 mm, Traversing path: 10 m, Traversing rate: 3 m/s, Acceleration: 10 m/s² Halogen-free: in accordance with DIN VDE 0472 part 815 Flame resistance: in accordance with UL 758/1581 FT2 According to DIN EN 60332-2-2 (20 s) Resistance to oil: in accordance with DIN EN 60811-2-1 Other resistance: Highly resistant to acids, alkaline solutions and solvents hydrolysis and microbe resistant partly UV-resistant (in accordance with DIN EN ISO 4892-2-A) Low adhesion abrasion-resistant Special properties: Flexible cable conduit capable Silicone-free Free of substances which would hinder coating with paint or varnish flexible Ambient temperature (operation): -40 °C ... 80 °C (cable, fixed installation) -25 °C ... 80 °C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 IP68 Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) -40 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation) |
| Standards and regulations | Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 |
