| Product properties | Product type: Data cable preassembled Sensor type: Ethernet Number of positions: 8 Shielded: yes Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 72 V Power transmission: PoE++ |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Brass Contact surface material: Au Contact carrier material: PC Outer sheath, material: LSZH |
| Connection data | Connection technology Connection method: Pierce connection Conductor connection Connection method: Pierce connection |
| Connector | Connection 1 Type: Plug straight RJ45 Handle color: green Insertion/withdrawal cycles: ââ°¥ 750 Degree of protection: IP20 Ambient temperature (operation): -20 °C ... 80 °C Connection 2 Type: Plug straight RJ45 Handle color: green Insertion/withdrawal cycles: ââ°¥ 750 Degree of protection: IP20 Ambient temperature (operation): -20 °C ... 80 °C |
| Cable/line | Cable length: 0.50 m Ethernet, Type B, 8-pos., CAT6A, LSZH [BC6A] Shielded: yes Cable type: Ethernet, Type B, 8-pos., CAT6A, LSZH Cable type (abbreviation): BC6A Cable structure: 4x2xAWG26/7; S/FTP External cable diameter: 6.50 mm ñ0.3 mm Outer sheath, material: LSZH External sheath, color: gray Thickness, outer sheath: approx. 0.70 mm Conductor material: Bare Cu litz wires Conductor structure signal line: 7x 0.16 mm AWG signal line: 26 Material wire insulation: PE Single wire, number of litz wires: 8 Wire diameter incl. insulation: 1 mm Single wire, cross section [AWG]: 26 Shielding: S/FTP Optical shield covering: 70 % Cable insulation resistance: ââ°¥ 5000 Mé*km Wave impedance: 100 é Loop resistance: ââ°¤ 148.00 é/km Minimum bending radius, fixed installation: 8 x D Near end crosstalk attenuation (NEXT): 75 dB (with 1 MHz) 66.3 dB (at 4 Ãà Hz) 60.3 dB (at 10 MHz) 57.2 dB (at 16 MHz) 55.8 dB (at 20 Ãà Hz) 52.9 dB (at 31.25 Ãà Hz) 48.4 dB (at 62.5 Ãà Hz) 45.3 dB (at 100 MHz) 40.8 dB (at 200 MHz) 38.1 dB (at 300 MHz) 36.3 dB (at 400 MHz) 34.8 dB (at 500 MHz) Power-summated near end crosstalk attenuation (PSNEXT): 72.3 dB (with 1 MHz) 63.3 dB (at 4 Ãà Hz) 58.8 dB (at 8 Ãà Hz) 57.3 dB (at 10 MHz) 54.2 dB (at 16 MHz) 52.8 dB (at 20 Ãà Hz) 51.3 dB (at 25 MHz) 49.9 dB (at 31.25 Ãà Hz) 45.4 dB (at 62.5 Ãà Hz) 42.3 dB (at 100 MHz) 37.8 dB (at 200 MHz) 35.1 dB (at 300 MHz) 33.3 dB (at 400 MHz) 31.8 dB (at 500 MHz) Return attenuation (RL): 20 dB (with 1 MHz) 23 dB (at 4 Ãà Hz) 24.5 dB (at 8 Ãà Hz) 25 dB (at 10 MHz) 25 dB (at 16 MHz) 25 dB (at 20 Ãà Hz) 24.2 dB (at 25 MHz) 23.3 dB (at 31.25 Ãà Hz) 20.7 dB (at 62.5 Ãà Hz) 19 dB (at 100 MHz) 16.4 dB (at 200 MHz) 15.6 dB (at 300 MHz) 15.6 dB (at 400 MHz) 15.6 dB (at 500 MHz) Halogen-free: complying with IEC 60754-1/2 Flame resistance: IEC 60332-1-2/IEC 60332-3-24/CM Ambient temperature (operation): -20 °C ... 80 °C (Cable, flexible installation) -20 °C ... 80 °C (cable, fixed installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20 °C ... 80 °C Ambient temperature (storage/transport): 0 °C ... 40 °C |
| Standards and regulations | Flame resistance: IEC 60332-1-2 |
