Non disponibile
| Product properties | Product type: Cable by the meter Number of positions: 8 Application: Connector Shielded: yes |
| Cable/line | Cable length: 100 m PVC blackÃ[PVC] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/3f57b5317f5d4b4fb418a4409e500605/-S204x204-FJPG Note: The cable is not suitable for use with drag chains. Cable weight: 85 kg/km UL AWM Style: 2517 Number of positions: 8 Shielded: yes Cable type: PVC blackÃ[PVC] Conductor structure signal line: 32x 0.10 mm AWG signal line: 24 Conductor cross section: 8x 0.25 mm² (Signal line) Wire diameter incl. insulation: 1.5 mm ñ0.05 mm (Signal line) External cable diameter: 7.7 mm ñ0.2Ãmm Outer sheath, material: PVC External sheath, color: black RALÃ9005 Conductor material: Bare Cu litz wires Material, filler: PVC Material wire insulation: PVC Single wire, color: white, brown, green, yellow, gray, pink, blue, red Thickness, insulation: ââ°¥ 0.38 mm (Conductor insulation, signal line) ââ°¥ 0.76 mm (Outer cable sheath) Overall twist: 8 wires around filler to the core, twisted in with additional Cu litz in the wire outer godet Optical shield covering: 85 % Max. conductor resistance: ââ°¤ 78 é/km Insulation resistance: ââ°¥ 10 Gé*km Nominal voltage, cable: 300 V Test voltage: 3000 V Smallest bending radius, fixed installation: 38.5 mm Smallest bending radius, movable installation: 77 mm Flame resistance: According to ULÃ758/1581 (Cable Flame) According to DIN ENÃ60332-1-2 (60 s) Resistance to oil: According to DIN EN 60811-2-1, 168 h at 80°C Ambient temperature (operation): -25°C ... 105°C (cable, fixed installation) |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -25°C ... 80°C (cable, fixed installation) -5°C ... 80°C (Cable, flexible installation) |
