| Product properties | Product type: Sensor/actuator cable Number of positions: 6 No. of cable outlets: 1 Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Zinc die-cast, nickel-plated |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 30 V AC 30 V DC Nominal current IN: 2 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Signaling | Status display: no Status display present: No |
| Connector | Connection 1 Type: free cable end Connection 2 Type: Socket straight M12 Number of positions: 6 Coding type: A |
| Cable/line | Cable length: 10 m PUR halogen-free yellow [240] Cable weight: 34 kg/km Number of positions: 6 Shielded: no Cable type: PUR halogen-free yellow [240] Conductor structure signal line: 32x 0.10 mm AWG signal line: 24 Conductor cross section: 0.25 mm² Wire diameter incl. insulation: 1.17 mm ñ0.02 mm External cable diameter: 5 mm Outer sheath, material: PUR External sheath, color: yellow Conductor material: Bare Cu litz wires Material, filler: PE Material wire insulation: PP Single wire, color: brown, white, green, yellow, gray, pink Thickness, insulation: ââ°¥ 0.21 mm (Core insulation) approx. 0.70 mm (Outer cable sheath) Overall twist: Six cores around the filler to the core Max. conductor resistance: ââ°¤ 78 é/km Insulation resistance: ââ°¥ 100 Gé*km Nominal voltage, cable: 300 V Test voltage: 3000 V Smallest bending radius, fixed installation: 50 mm Smallest bending radius, movable installation: 50 mm Dynamic load capacity (bending): Max. bending cycles: 4000000, Bending radius: 50 mm, Traversing path: 10 m, Traversing rate: 3 m/s, Acceleration: 10 m/s² Halogen-free: in accordance with DIN VDE 0472 part 815 Flame resistance: in accordance with DIN UL-Style 20549 Special properties: Flexible cable conduit capable Ambient temperature (operation): -40 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 IP68 Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) |
