| Product properties | Product type: Circular connectors (device side) Sensor type: PROFINET Number of positions: 4 Shielded: yes Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: PA 6.6 Material for screw connection: Zinc die-cast, nickel-plated Outer sheath, material: PE-X |
| Electrical properties | Nominal voltage UN: 48 V AC Nominal current IN: 4 A (Plug/socket in accordance with IEC 61076-2-101, cable technical data is to be observed) |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Connector | Connection 1 Type: Plug straight M12 Coding type: A (Standard) Connection 2 Type: Flush-type female connector M12 Coding type: A (Standard) |
| Cable/line | Cable length: 1.00 m PROFINET RADOXî railway application CAT5 reinforced [936] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9154/full/b1500?format=jpg Cable weight: 81 g/m Number of positions: 4 Shielded: yes Cable type: PROFINET RADOXî railway application CAT5 reinforced [936] Conductor structure: 1x4xAWG22/7, SF/TQ Signal speed: 66 c Conductor structure signal line: 7x 0.25 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² Wire diameter incl. insulation: 1.95 mm External cable diameter: 7.25 mm ñ0.3 mm Outer sheath, material: PE-X External sheath, color: black RAL 9005 Conductor material: silver-plated Cu litz wires Material wire insulation: PE-X Single wire, color: white-blue, orange-yellow Thickness, outer sheath: ââ°¥ 0.80 mm Overall twist: Star quad Optical shield covering: 100 % Max. conductor resistance: ââ°¤ 54.4 é/km Coupling resistance: 200.00 mé/m (f ââ°¤ 30 MHz) Wave impedance: 100 é ñ5 é (f = 100 MHz) Working capacitance: ââ°¤ 65 pF (Line-line) ââ°¤ 100 pF (Line-shield) Nominal voltage, cable: 300 V AC Test voltage: 2000 V AC (50 Hz, 5 minutes) Minimum bending radius, fixed installation: 6 x D Minimum bending radius, flexible installation: 10 x D Smallest bending radius, fixed installation: 44 mm Smallest bending radius, movable installation: 73 mm Near end crosstalk attenuation (NEXT): 80 dB (with 1 MHz) 76 dB (at 4 Ãà Hz) 67 dB (at 10 MHz) 60 dB (at 31.5 Ãà Hz) 56 dB (at 62.5 Ãà Hz) 53 dB (at 100 MHz) Return attenuation (RL): 35 dB (at 4 Ãà Hz) 35 dB (at 10 MHz) 35 dB (at 31.5 Ãà Hz) 33 dB (at 62.5 Ãà Hz) 33 dB (at 100 MHz) Remote crosstalk attenuation (FEXT): 80 dB (with 1 MHz) 70 dB (at 4 Ãà Hz) 65 dB (at 10 MHz) 58 dB (at 31.5 Ãà Hz) 59 dB (at 62.5 Ãà Hz) 67 dB (at 100 MHz) Shield attenuation: 2 dB (with 1 MHz) 4 dB (at 4 Ãà Hz) 6.5 dB (at 10 MHz) 10.5 dB (at 31.5 Ãà Hz) 14 dB (at 62.5 Ãà Hz) 18 dB (at 100 MHz) 40.00 dB (30 MHz ââ°¤ f ââ°¤ 100 MHz) Halogen-free: in accordance with EN 50267-2-1 Flame resistance: EN 60332-1-2 EN 50266 EN 60332-3-25 NF C32-070, 2.1 NF C32-070, 2.2 UL 1685, 12 (FT4) in accordance with ISO 6722-1 5.22 (UN ECE-R 118.01) Fume corrosiveness: EN 50267-2-2 Fume toxicity: BS 6853 B.1 EN 50305, 9.2 Concentration of fumes: BS 6853 D.8.7 EN 61034-2 UL 1685, 12 (FT4) Resistance to oil: according to IRM 902, 72 h at 100 °C Fire protection in rail vehicles: BS 6853 (Category Ia, Ib, II) GM/RT 2130 (Category Ia, Ib, II) EN 45545 (Risk level HL1 - HL3) DIN 5510 (Fire protection level 1, 2, 3, 4) NF F16-101 (Category A1, A2, B) NF F16-101 (Class C/F0) NFPA 130 UNI CEI 11170 (Risk level LR1 - LR4) Other resistance: Resistance to fuels (according to IRM 903, 168 h at 70 °C) Ambient temperature (operation): -50 °C ... 90 °C (cable, fixed installation) -40 °C ... 90 °C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP68 IP69K IP65/IP68/IP69K Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) -40 °C ... 90 °C (cable, fixed installation) -25 °C ... 90 °C (Cable, flexible installation) |
