SAC-4P-M12MS/15,0-990 - Bus system cable

Bus system cable, CC link (10 Mbps), 4-position, shielded, Plug straight M12, coding: A, on free cable end, cable length: 15 m

Cod. Articolo: 1558357 copia - copy

Cod. Fornitore: 1558357 copia - copy

PHOENIX CONTACT

Product properties	Product type: Data cable preassembled Sensor type: CC link Number of positions: 4 Application: Standard No. of cable outlets: 1 Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3
Interfaces	Signal type/category: CC link, 10 Mbps
Signaling	Status display: No Status display present: No
Electrical properties	Contact resistance: Ã¢Ã¢°¤ 5 mÃ© Insulation resistance: Ã¢Ã¢°¥ 100 MÃ© Nominal voltage U_N: 48 VÃAC 60 VÃDC Nominal current I_N: 4 A Transmission medium: Copper
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 100
Material specifications	Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Zinc die-cast, nickel-plated
Connection data	Pin assignment Contact \| Color (signal designation) \| Contact (optional): 1 (Plug) \| SR (shield) 2 (Plug) \| WH (DB) 3 (Plug) \| YE (DG) 4 (Plug) \| BU (DA)
Connector	Connection 1 Type: Plug straight M12 Number of positions: 4 Coding type: A (Standard) Connection 2 Type: free cable end
Cable/line	Cable length: 15 m CC-LinkÃ[990] Cable weight: 78.8 kg/km Number of positions: 3 Shielded: yes Cable type: CC-LinkÃ[990] Conductor structure: 3xAWG20/7 + 1xAWG22/19 (filler litz wire) Conductor structure signal line: 7x 0.28 mm AWG signal line: 20 Conductor cross section: 0.5 mm² External cable diameter: 7.7 mm Outer sheath, material: PVC External sheath, color: red Conductor material: Bare Cu litz wires Material wire insulation: foamed PE, with high density Single wire, color: white, yellow, blue Thickness, insulation: 0.89 mm (Outer cable sheath) Optical shield covering: 78 % Max. conductor resistance: 31.2 Ã©/km Wave impedance: 110 Ã© Working capacitance: 61 pF Nominal voltage, cable: 300 V Smallest bending radius, fixed installation: 77 mm Ambient temperature (operation): -30°C ... 60°C (cable, fixed installation) -5°C ... 60°C (Cable, flexible installation)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 IP67 Ambient temperature (operation): -25°C ... 90°C (Plug / socket)
