1566491 PHOENIX CONTACT -

SAC-2P-MS/0,25-PUR/ZC-1L-S STS - Sensor/actuator cable

Sensor/actuator cable, 2-pos, PUR/PVC gray, straight M12 SPEEDCON plug on valve connector type MSZC, with one LED, cable length: 0.25 m

Cod. Articolo: 1566491 copia - copy

Cod. Fornitore: 1566491 copia - copy

PHOENIX CONTACT

Product properties	Product type: Sensor/actuator cable Number of positions: 3 No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3
Material specifications	Flammability rating according to UL 94: HB Seal material: NBR Material housing valve plug: TPE-U Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: TPU GF
Electrical properties	Contact resistance: Ã¢Ã¢°¤ 5 mÃ© Insulation resistance: Ã¢Ã¢°¥ 100 MÃ© Nominal voltage U_N: 250 VÃAC 250 VÃDC Nominal current I_N: 4 A Protective circuit: Protective circuit and holding current reduction
Signaling	Status display: 1 LED Status display present: Yes
Connection data	Conductor connection Tightening torque: 0.4 Nm
Connector	Connection 1 Type: Plug straight M12 SPEEDCON Number of positions: 3 Coding type: A Material: CuSn (Contact) Ni/Au (Contact surface) TPU GF (Contact carriers) Locking type: SPEEDCON Connection 2 Type: Valve connector Festo ZC Number of positions: 3 Material: CuSn (Contact) TPE-U (Housing)
Cable/line	Cable length: 0.25 m PUR grayÃ[PUR] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/bd1a178df365f342b810def79898d2a5/-S204x204-FJPG Number of positions: 2 Shielded: no Cable type: PUR grayÃ[PUR] AWG signal line: 24 Conductor cross section: 2x 0.25 mm² (Signal line) External cable diameter: 3.4 mm Outer sheath, material: PUR External sheath, color: gray RAL 7001 Conductor material: Bare Cu litz wires Single wire, color: black, black Ambient temperature (operation): -10°C ... 50°C (cable, fixed installation) -10°C ... 50°C (Cable, flexible installation)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 (M12 connector) IP67 (M12 connector) IP65 (Valve connector) Ambient temperature (operation): -10°C ... 50°C (valve plug) -30°C ... 80°C (cable, fixed installation) -5°C ... 70°C (Cable, flexible installation)
