1652677 PHOENIX CONTACT -

VS-15-GC-ST/ST - D-SUB gender changer

D-SUB contact insert, shell size 2, with 15 signal contacts, type of contact pin, gender changer, fixing with 4-40 UNC thread

Cod. Articolo: 1652677 copia - copy

Cod. Fornitore: 1652677 copia - copy

PHOENIX CONTACT

Product properties	Type: D-SUB Male/Male Product type: Male insert Sensor type: Universal Number of positions: 15 Shielded: no Cable outlet: straight Insulation characteristics Overvoltage category: III Degree of pollution: 2
Electrical properties	Rated voltage (III/3): 125 V Rated surge voltage: 1 kV Rated current: 5 A Transmission medium: Copper
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/92c2fc6a302a3b489333c58c7c8bf45b/-S204x204-FJPG Width: 12.55 mm Height: 39.3 mm Length: 17.66 mm
Material specifications	Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Hard gold-plated over nickel Contact carrier material: Polyester GF Housing material: Stainless steel
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 200
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 125°C
Mounting	Mounting type: Threads Connection method: Gender changer
