1652680 PHOENIX CONTACT -

VS-25-GC-BU/BU - D-SUB gender changer

D-SUB contact insert, shell size 3, with 25 signal contacts, type of contact socket, gender changer, fixing with 4-40 UNC thread

Cod. Articolo: 1652680 copia - copy

Cod. Fornitore: 1652680 copia - copy

PHOENIX CONTACT

Product properties	Type: D-SUB Female/Female Product type: Female insert Sensor type: Universal Number of positions: 25 Connection profile: D-SUB Shielded: no Cable outlet: straight Insulation characteristics Overvoltage category: III Degree of pollution: 2
Electrical properties	Rated voltage (III/3): 125 V Rated surge voltage: 1 kV Rated current: 5 A Transmission medium: Copper Power transmission: Power
Connection data	Connection technology Connection method: Coupling
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/851ffbc22e6beb4594af33847ffaed12/-S204x204-FJPG Width: 17.8 mm Height: 53.06 mm Length: 12.55 mm
Material specifications	Flammability rating according to UL 94: V0 Housing surface material: metal-plated Contact material: Copper alloy Contact surface material: Gold Contact carrier material: Polyester GF Housing material: Metal
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 200
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 125°C
Mounting	Mounting type: Threads Connection method: Coupling
