Non disponibile
| Notes | General: This product corresponds to the PROFINET Cabling and Interconnection Technology Guideline for PROFINET regulations, version 2.00, order no: 2.252, Chapter 8.3 Connectors for inside environment (optical fibre) |
| Product properties | Type: SC-RJ Product type: Data connector (cable side) Number of positions: 2 Connection profile: SC-RJ Application: neutral Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Attenuation: ââ°¤ 1.5 dB (Insertion attenuation) Transmission medium: FO Transmission characteristics (category): MM |
| Connection data | Connection technology Connection method: Push-Pull |
| Dimensions | Width: 16.5 mm Height: 11 mm Length: 83 mm |
| Material specifications | Color: black Material: Plastic Flammability rating according to UL 94: V0 Ferrule material: Copper alloy Housing surface material: nickel-plated Housing material: Metal |
| Cable/line | Cable type: Plastic fiber External cable diameter (): 2.2 mm ... 2.2 mm External cable diameter: ââ°¤ 3 mm Wire diameter: 2.2 mm Individual wire diameter: 2.2 mm Flame resistance: yes FO cable Number of fibers: 2 Fiber: 980/1000Ãõm Fiber type: POF |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 |
| Characteristics | Attenuation: ââ°¤ 1.5 dB (Insertion attenuation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -25°C ... 70°C Ambient temperature (storage/transport): -25°C ... 70°C Ambient temperature (assembly): 0°C ... 50°C |
| Standards and regulations | Flame resistance: yes |
| Mounting | cable layer type: Indoors Connection method: Push-Pull |
