Non disponibile
| Product properties | Product type: Contacts Type: Individual female contact Contact material type: turned |
| Electrical properties | Maximum load current: 40 A Rated surge voltage: 1 kV Rated current: 40 A (at 20ðC) Insulation resistance: ââ°¥ 5 Gé Test voltage: 1000 V |
| Connection data | Maximum load current: 40 A |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/00a04ae1cf38d7408e8a44983ab8e6ba/-S204x204-FJPG Width: 13.8 mm Height: 19.9 mm Length: 5.5 mm Mechanical characteristics Contact diameter: 3.8 mm |
| Material specifications | Material: Metal Contact material: Copper alloy Contact surface material: Au/Sn |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 Insertion force per signal contact: ââ°¤ 7.00 N Extraction force per signal contact: approx. 5 N |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -55°C ... 130°C |
| Mounting | Mounting type: Solder connection Connection method: PCB mounting |
