| Product properties | Type: D-SUB Male Product type: Male insert Number of positions: 15 Connection profile: D-SUB 15 Shielded: no Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated voltage in acc. with IEC 61076-2-101: 400 V Rated voltage (III/3): 125 V Rated surge voltage: 1 kV Rated current: 5 A (at 20ðC) Test voltage: 1200 V Transmission medium: Copper |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/b9aac9da85905a4db1baf6e4ebdb0c0c/-S204x204-FJPG Width: 21.4 mm Height: 17.6 mm Length: 39.52 mm |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Hard gold-plated over nickel Contact carrier material: PBT-GF Housing material: Steel, tin-plated |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 50 Insertion force per signal contact: ââ°¤ 3.40 N |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 125°C |
| Mounting | Mounting type: Threads and solder pins Connection method: PCB connection |
