| Notes | General: Power contacts must be ordered separately since they are not included in the scope of supply of the contact carriers. |
| Product properties | Product type: Contacts Type: Individual female contact Contact material type: turned |
| Electrical properties | Maximum load current: 20 A Rated surge voltage: 1 kV Rated current: 20 A (at 20ðC) Insulation resistance: ââ°¥ 5 Gé Test voltage: 1000 V |
| Connection data | Maximum load current: 20 A |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/fa686eb18f33b2449b66eaae5413f3d2/-S204x204-FJPG Length: 23 mm Mechanical characteristics Contact diameter: 2.6 mm |
| Material specifications | Material: Metal Contact material: Copper alloy Contact surface material: Au/Sn |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 Insertion force per signal contact: ââ°¤ 7.00 N Extraction force per signal contact: approx. 5 N |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -55°C ... 130°C |
| Mounting | Mounting type: Solder connection Connection method: Solder cup |
