| Notes | Safety note Safety note: ̢̢¢ VDE 0100/1.97 ̤ 411.1.3.2 and DIN EN 60 204/11.98 ̤ 14.1.3 are applicable when combining several circuits in a cable and/or connector |
| Product properties | Type: D-SUB Socket Product type: Female insert Number of positions: 9 Connection profile: D-SUB Number of slots: 1 Shielded: yes Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated voltage in acc. with IEC 61076-2-101: 400 V Rated voltage (III/3): 125 V Rated surge voltage: 1 kV Rated current: 5 A (at 20ðC) Test voltage: 1200 V Transmission medium: Copper Power transmission: Power |
| Connection data | Connection technology Connection method: Wave soldering contacts |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/d350d5a294caa04ca023711364299d8d/-S204x204-FJPG Width: 21.6 mm Height: 17.6 mm Length: 31.19 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing surface material: metal-plated Contact material: Copper alloy Contact surface material: Gold Contact carrier material: PBT-GF Housing material: Metal |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 50 Insertion force per signal contact: ââ°¤ 3.40 N |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 125°C |
| Mounting | Mounting type: Screw mounting Connection method: Wave soldering contacts |
