Non disponibile
| Notes | General: The contacts must be ordered separately since they are not included in the scope of supply of the contact carriers. Both one male and one female contact must be mounted in the contact carrier. |
| Product properties | Type: D-SUB Male Product type: Male insert Number of positions: 2 Connection profile: D-SUB Shielded: no |
| Electrical properties | Transmission medium: Copper |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/9720142e7f5e594e8ce9e5835b1e7837/-S204x204-FJPG Width: 12.5 mm Height: 12.93 mm Length: 31.2 mm |
| Material specifications | Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Gold over nickel Contact carrier material: PBTP Housing material: Steel, yellow chromated |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 125°C |
| Mounting | Mounting type: Hole Connection method: D-SUB |
