1689268 PHOENIX CONTACT -

Product properties	Product type: Female insert Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 No. of cable outlets: 1 Number of slots: 1 Housing type: Plastic sleeve housing Shielded: no Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 1
Electrical properties	Rated voltage (III/3): 72 V (DC) Rated surge voltage: Ã¢Ã¢°¥ 1 kV Rated current: 1 A Insulation resistance: Ã¢Ã¢°¥ 500 MÃ© Nominal voltage U_N: 48 V Transmission medium: Copper Transmission characteristics (category): CAT5
Connection data	Connection technology Connection method: Coupling
Material specifications	Color: gray Flammability rating according to UL 94: V0 Seal material: NBR Contact material: Copper alloy Contact surface material: Gold over nickel Contact carrier material: Thermoplastic Housing material: Plastic
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 750
Environmental and real-life conditions	Ambient conditions Degree of protection: IP67 IP65/IP67 Ambient temperature (operation): -10°C ... 60°C Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 55°C
Mounting	Connection method: Coupling
