1689323 PHOENIX CONTACT -

Notes	General: Only actuate MINI COMBICON connectors when under no load condition. If for operating reasons small loads must be switched, experimental values are available upon request.
Product properties	Type: 15 Male Product type: Contact insert Number of positions: 5 Application: leading PE contact Insulation characteristics Overvoltage category: III Degree of pollution: 3
Electrical properties	Rated voltage (III/3): 250 V Rated surge voltage: 4 kV Rated current: 8 A Contact resistance: 3 mÃ© Insulation resistance: 1 TÃ© Transmission medium: Copper
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/27fe4cc6d80be84ab651ba210dc23122/-S204x204-FJPG Width: 39.1 mm Height: 13.7 mm Length: 20.8 mm
Material specifications	Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: tin-plated Contact carrier material: PA
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 100
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 80°C
Mounting	Mounting type: Threads Connection method: PCB connection
