| Notes | Order information:: The contacts must be ordered separately since they are not included in the scope of supply of the contact carriers. |
| Product properties | Product type: Female insert Type: D-SUB Socket Number of positions: 5 Connection profile: D-SUB Number of slots: 1 Shielded: yes Data management status Article revision: 02 |
| Electrical properties | Transmission medium: Copper |
| Connection data | Connection technology Connection method: Wave soldering contacts |
| Dimensions | Width: 12.6 mm Height: 12.93 mm Length: 53.42 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing material: Metal Housing surface material: metal-plated Contact material: Copper alloy Contact surface material: Gold Contact carrier material: PBTP |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55 °C ... 125 °C |
| Mounting | Mounting type: Screw mounting |
