| Product properties | Product type: Sensor/actuator cable Number of positions: 5 No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Zinc die-cast, nickel-plated |
| Electrical properties | Rated voltage in acc. with IEC 61076-2-101: 60 V Contact resistance: ââ°¤ 5 mé Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 24 V Nominal current IN: 4 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Signaling | Status display: 3 LEDs Status display present: Yes |
| Connector | Connection 1 Type: Plug straight M12 Number of positions: 5 Coding type: A Connection 2 Type: Socket angled M12 Number of positions: 5 Coding type: A |
| Cable/line | Cable length: 1.5 m PUR irradiated halogen-free orangeÃ[150] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/8223765d80f18f46aa9c1d14b78df6c1/-S204x204-FJPG Number of positions: 5 Shielded: no Cable type: PUR irradiated halogen-free orangeÃ[150] Conductor structure signal line: 42x 0.10 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² (Signal line) 1x 0.5 mm² (PE connection) External cable diameter: 5.2 mm ñ0.2Ãmm Outer sheath, material: PUR External sheath, color: orange RALÃ2003 Conductor material: Bare Cu litz wires Material wire insulation: PE Single wire, color: brown, white, blue, black, green-yellow Overall twist: 5 cores, twisted Max. conductor resistance: ââ°¤ 57.5 é/km (with 0.34 mm² conductor cross section) ââ°¤ 39 é/km (with 0.5 mm² conductor cross section) Nominal voltage, cable: 250 V (AC) Test voltage: 2000 V (50 Hz, 5 minutes) Smallest bending radius, fixed installation: 20 mm Smallest bending radius, movable installation: 30 mm Max. bending cycles: 5000000 Halogen-free: The cable is halogen-free Flame resistance: DINÃVDEÃ0472 part 804, test type B Other resistance: hydrolysis and microbe resistant UV resistant Resistant to welding splashes Special properties: Silicone-free Irradiated Ambient temperature (operation): -50°C ... 105°C (cable, fixed installation) -40°C ... 105°C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 IP68 Ambient temperature (operation): -25°C ... 90°C (Plug / socket) -50°C ... 105°C (cable, fixed installation) -40°C ... 105°C (Cable, flexible installation) |
