| Notes | General: Refer to the data sheet for the range in the download area. |
| Product properties | Product type: Upper housing part Type: Cover Housing type: DIN rail housing Ventilation openings present: no Housing series: ME PLC |
| Dimensions | Width: 39.7 mm Height: 51.8 mm Depth: 13.65 mm |
| Material specifications | Color: transparent Color (Housing): transparent Flammability rating according to UL 94: V0 CTI according to IEC 60112: 225 Surface characteristics: untreated Housing material: Polycarbonate |
| Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 100°C Relative humidity (storage/transport): 95 % |
| Mounting | Mounting type: Latching with lower housing part Mounting position: Vertical (horizontal DIN rail) |
| Packaging specifications | Type of packaging: packed in cardboard Outer packaging type: Carton |
