2202993 PHOENIX CONTACT -

Product properties	Type: Pin strip Product type: Pin strip Product family: PSTD 0,65X0,65/..-V Number of positions: 18 Pitch: 2.54 mm Number of connections: 18 Number of rows: 2 Number of potentials: 18 Pin layout: Linear pinning
Electrical properties	Degree of pollution: 3 Contact resistance: 35.7 mÃ©
Mounting	Mounting type: THR soldering Pin layout: Linear pinning
Material specifications	Material data - housing Color (Housing): black (9005) Insulating material: PA Flammability rating according to UL 94: V0
Dimensions	Pitch: 2.54 mm Width [w]: 22.86 mm Height [h]: 37.8 mm Length [l]: 5 mm Pin dimensions: 0.635 x 0.635 mm
Mechanical tests	Visual inspection Specification: IEC 60512-1-1:2002-02 Result: Test passed Dimension check Specification: IEC 60512-1-2:2002-02 Result: Test passed
Environmental and real-life conditions	Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 150 - 10 Hz Sweep speed: 1Ãoctave/min 20Ãm/s² Amplitude: 0.15Ãmm (10ÃHzÃ...Ã58.1ÃHz) Test duration per axis: 2.5 h Durability test Specification: IEC 60512-9-1:2010-03 Impulse withstand voltage at sea level: 1.75 kV Contact resistance R₁: 35.7 mÃ© Contact resistance R₂: 35.7 mÃ© Insertion/withdrawal cycles: 25 Climatic test Specification: DINÃ50018:2013-05 Corrosive stress: 0.2 dm³SO₂on 300 dm³/40°C/1 cycle Thermal stress: 100Ã°C/168Ãh Power-frequency withstand voltage: 0.84 kV Shocks Specification: IEC 60068-2-27:2008-02 Pulse shape: Semi-sinusoidal Acceleration: 150Ãm/s² Shock duration: 11Ãms Test directions: X-, Y- and Z-axis (pos. and neg.)
