2402980 PHOENIX CONTACT -

Product properties	Product type: Monitor Computer data Processor: without Operating system: without operating system Cooling: passive RAM: without RAM Data storage system: without data storage Slots: without slots Optical drive: without drive Display Display type: 39.6 cm/15.6" TFT Screen resolution: 1366ÃxÃ768ÃPixel(s)Ã(WXGA) Touch technology: projective-capacitive, ten-touch control Display lighting type: LED Brightness: 300 cd/m², typical (adjustable) MTBF: > 50000 h Color spectrum: 16.7 million colors
Electrical properties	Supply Supply voltage: 24 VÃDC (Ã±10Ã%) Power supply unit: 24 V DC Max. current consumption: 0.59 A
Connection data	Connection method: Screw connection Conductor cross section, rigid: 0.2 mm² ... 2.5 mm² Conductor cross section, flexible: 0.2 mm² ... 2.5 mm² Conductor cross section AWG: 24 ... 12 Stripping length: 7 mm
Interfaces	Interfaces: 1x USB Type A (For touch control only) Monitor output: 1x DisplayPort 1x DVI-D 1x VGA Network: Without network
Dimensions	External dimensions Width / Height / Depth: 417 mm / 312 mm / 51 mm Installation dimensions Width / Height / Installation depth: 401 mm / 296 mm /
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 (front), IP20 (back) Ambient temperature (operation): -10°C ... 60°C Ambient temperature (storage/transport): -20°C ... 75°C Permissible humidity (operation): 10 % ... 90 % (non-condensing) Shock: 15g, 11 ms impulse Vibration (operation): 1g
Mounting	Mounting type: Front mounting VESA holder Holder system: VESA MIS-D 100 C
