2723123 PHOENIX CONTACT -

IBS RBC METER/F-T - Remote bus cable

By the meter, Remote bus cable, INTERBUS, shielded, PUR halogen-free, may green RAL 6017, 6-wire (3 x 2 x 0.22 mm²), color single wire: green-yellow, white-brown, gray-pink, flexible installation

Cod. Articolo: 2723123 copia - copy

Cod. Fornitore: 2723123 copia - copy

PHOENIX CONTACT

Product properties	Product type: Remote bus cable Number of positions: 6
Electrical properties	Transmission medium: Copper
Cable/line	INTERBUSÃ[900] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/e9510efa11ce95448a7ed1ffa1fb852c/-S204x204-FJPG Cable weight: 70 kg/km Number of positions: 6 Shielded: yes Cable type: INTERBUSÃ[900] Conductor structure: 3 x 2 x 0.22 mm² Signal speed: 0.66 c Conductor structure signal line: 32x 0.10 mm AWG signal line: 24 Conductor cross section: 3x 2x 0.22 mm² External cable diameter: 8 mm Outer sheath, material: PUR External sheath, color: may green RAL 6017 Conductor material: Bare Cu litz wires Material wire insulation: PE Single wire, color: green-yellow, white-brown, gray-pink Twisted pairs: 2 cores to the pair Overall twist: 3 pairs to the core Insulation resistance: Ã¢Ã¢°¥ 5 GÃ©*km Coupling resistance: < 250.00 mÃ©/m (at 30 MHz) Loop resistance: Ã¢Ã¢°¤ 159.80 Ã©/km Wave impedance: 120 Ã© Ã±20Ã% (at 64ÃkHz) 100 Ã© Ã±15Ã% (with 1 MHz) Cable capacity: Ã¢Ã¢°¤ 60 nF/km (At 800 Hz) Nominal voltage, cable: 250 V (Peak value, not for high-power applications) Test voltage Core/Core: 1500 V_rms Test voltage Core/Shield: 1000 V_rms Minimum bending radius, fixed installation: 7.5 x D Minimum bending radius, flexible installation: 15 x D Max. bending cycles: 5000000 Near end crosstalk attenuation (NEXT): Ã¢Ã¢°¥ 61 dB (at 772ÃkHz) Ã¢Ã¢°¥ 59 dB (with 1 MHz) Ã¢Ã¢°¥ 55 dB (at 2ÃÃÃHz) Ã¢Ã¢°¥ 50 dB (at 4 ÃÃHz) Ã¢Ã¢°¥ 46 dB (at 8ÃÃÃHz) Ã¢Ã¢°¥ 44 dB (at 10 MHz) Ã¢Ã¢°¥ 41 dB (at 16 MHz) Ã¢Ã¢°¥ 40 dB (at 20ÃÃÃHz) Shield attenuation: Ã¢Ã¢°¤ 15 dB/km (at 256ÃkHz) Ã¢Ã¢°¤ 24 dB/km (at 772ÃkHz) Ã¢Ã¢°¤ 27 dB/km (with 1 MHz) Ã¢Ã¢°¤ 52 dB/km (at 4 ÃÃHz) Ã¢Ã¢°¤ 84 dB/km (at 10 MHz) Ã¢Ã¢°¤ 112 dB/km (at 16 MHz) Ã¢Ã¢°¤ 119 dB/km (at 20ÃÃÃHz) Flame resistance: according to VDEÃ0472, Part 4, test type B according to IEC 60332-1 Ambient temperature (operation): -40°C ... 80°C (cable, fixed installation) -30°C ... 70°C (Cable, flexible installation)
