PHOENIX CONTACT 2735386
PHOENIX CONTACT 2735386
PHOENIX CONTACTNon disponibile

EG 45-GMFP/PC GY - Mounting base housing

Housing base, with metal foot catch and test opening with side cover
Cod. Articolo: 2735386 copia - copy
Cod. Fornitore: 2735386 copia - copy
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Caratteristiche Tecniche
Download
Caratteristiche Tecniche
Product propertiesType: Lower housing parts with test opening with side cover, housing cover necessary to complete the module
Lower housing part with metal foot catch and test opening with side cover
Product type: Enclosure bottom part
Product family: EG G PC
Number of positions: 16
Housing type: Component housing
Ventilation openings present: no
Housing series: EG
DimensionsDimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/fdd7f57abcbd3549ae1e3573c4fc7dee/-S204x204-FJPG
Width: 45 mm
Height: 75 mm
PCB design
PCB thickness: 1.4 mm ... 1.8 mm
Material specificationsColor: gray (7040)
Flammability rating according to UL 94: V0
Surface characteristics: untreated
Housing material: Polycarbonate
Environmental and real-life conditionsAmbient conditions
Degree of protection: IP20
Max. IP code to attain: IP20
Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation)
Ambient temperature (storage/transport): -40°C ... 70°C
Ambient temperature (assembly): -5°C ... 100°C
PCB dataThickness of the PCB: 1.4 mm ... 1.8 mm
MountingMounting type: DIN rail mounting
Mounting position: Vertical (horizontal DIN rail)
