2744856 PHOENIX CONTACT -

FL PLUG RJ45 GR/2 - RJ45 connector

RJ45 connector, design: RJ45, degree of protection: IP20, number of positions: 8, 1 Gbps, CAT5 (IEC 11801:2002), material: Plastic, connection method: Crimp connection, connection cross section: AWG 26- 24, cable outlet: straight, color: gray, Ethernet

Cod. Articolo: 2744856 copia - copy

Cod. Fornitore: 2744856 copia - copy

PHOENIX CONTACT

Product properties	Type: RJ45 Product type: Data connector (cable side) Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 Cable outlet: straight Positions/contacts: 8P8C Insulation characteristics Overvoltage category: I Degree of pollution: 2
Electrical properties	Contact resistance: < 100 mÃ© (max.) > 10 mÃ© Frequency range: 100 MHz Insulation resistance: > 500 MÃ© Nominal current I_N: 1.5 A Contact resistance per contact pair: < 20 Ã© Transmission medium: Copper Transmission characteristics (category): CAT5 Transmission speed: 1 Gbps
Connection data	Connection technology Connection method: Crimp connection Connection cross section AWG: 26 ... 24 (solid) 26 ... 24 (flexible) Conductor cross section: 0.14 mm² ... 0.22 mm² (solid) 0.14 mm² ... 0.22 mm² (flexible)
Dimensions	Width: 13.7 mm Height: 13.1 mm Length: 32.7 mm
Material specifications	Color: gray Flammability rating according to UL 94: V0 Contact material: Phosphor bronze Contact surface material: Au/Ni Contact carrier material: PC Locking latch material: PC Housing material: Plastic
Cable/line	External cable diameter (): 4.6 mm ... 5.8 mm Test voltage Core/Core: 1000 V Test voltage Core/Shield: 1500 V
Mechanical properties	Mechanical data Insertion/withdrawal cycles: min. 2500 Insertion force per signal contact: < 20.00 N Extraction force per signal contact: < 20 N
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 85°C
Mounting	Mounting type: Crimp connection Connection method: Crimp connection
