2761596 PHOENIX CONTACT -

SUBCON 15/F-SH - D-SUB bus connector

D-SUB connector, 15-pos. female connector, one 35° cable entry, universal type for all systems, pin assignment: 1, 2, 3, ..., 14, 15 to screw connection terminal block

Cod. Articolo: 2761596 copia - copy

Cod. Fornitore: 2761596 copia - copy

PHOENIX CONTACT

Notes	Utilization restriction CCCex note: Use in potentially explosive areas is not permitted in China.
Product properties	Product type: Data plug MTTF: 6706 Years (SNÃ29500 standard, temperatureÃ25°C, operating cycleÃ21%) 1817 Years (SNÃ29500 standard, temperatureÃ40°C, operating cycleÃ34.25%) 155 Years (SNÃ29500 standard, temperatureÃ40°C, operating cycleÃ100%) Pin assignment: All connections are 1:1 on the screw terminal block
Electrical properties	Nominal voltage U_N: 50 VÃDC Nominal current I_N: 100 mA Transmission medium: Copper
Connection data	D-SUB connection Connection method: D-SUB socket PCB connection Connection method: Screw connection Stripping length: 5 mm Conductor cross section, rigid min.: 0.14 mm² Conductor cross section, rigid max.: 1.5 mm² Conductor cross section flexible min.: 0.14 mm² Conductor cross section flexible max.: 1 mm² Single-wire/terminal point, rigid AWG min.: 26 Single-wire/terminal point, rigid AWG max.: 16 Min. AWG conductor cross section, flexible: 26 Max. AWG conductor cross section, flexible: 18
Interfaces	Signal: Modbus
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/b5611dc3eb479c48ac578abe02da42c1/-S204x204-FJPG Width: 16 mm Height: 55 mm Length: 65 mm
Material specifications	Material: ABS, metal-plated
Cable/line	External cable diameter (): 4 mm ... 10 mm (Incoming bus line)
Mechanical properties	Mechanical data Insertion/withdrawal cycles: > 200
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 75°C Ambient temperature (storage/transport): -25°C ... 80°C Altitude: Ã¢Ã¢°¤ 5000 m (For restrictions, see the manufacturer's declaration for altitude operation) Permissible humidity (operation): 10 % ... 95 % (non-condensing) Permissible humidity (storage/transport): 5 % ... 95 % (non-condensing)
Approvals	ATEX Identification: Ã¯Ã II 3 G Ex nA IIC T4 Gc X Note: Please follow the special installation instructions in the documentation! Corrosive gas test Identification: ISA-S71.04-1985 G3 Harsh Group A
Standards and regulations	Free from substances that could impair the application of coating: in accordance with VW-AUDI-Seat central standard P-VW 3.10.7 57 65 0
