2810638 PHOENIX CONTACT -

MACX MCR-SL-CAC-12-I-UP - Current transducers

Current measuring transducer for 5 A and 12 A AC, the output signal 0...20 mA or 4...20 mA, can be configured using a DIP switch with an operating mode indication through an LED

Cod. Articolo: 2810638 copia - copy

Cod. Fornitore: 2810638 copia - copy

PHOENIX CONTACT

Notes	Utilization restriction EMC note: EMC: class A product, see manufacturer's declaration in the download area
Product properties	Product type: Current transducer Insulation characteristics Overvoltage category: III Pollution degree: 2
Electrical properties	Maximum power dissipation for nominal condition: < 0.9 W (24ÃVÃDC) < 3.4 W (230 V AC) Protective circuit: Surge protection; 35ÃV suppressor diode Step response (10-90%): Ã¢Ã¢°¤ 300 ms 200 ms Maximum temperature coefficient: < 0.02 %/K Temperature coefficient, typical: < 0.015 %/K Maximum transmission error: Ã¢Ã¢°¤ 0.5 % (of nominal range value under nominal conditions) Reverse polarity protection: yes Rated insulation voltage: 300 VÃAC (to earth) Electrical isolation Input/output Test voltage: 4 kV AC (50ÃHz, 60Ãs) Electrical isolation Output/supply Test voltage: 2 kV AC (50ÃHz, 60Ãs) Supply Supply voltage range: 19.2 V AC/DC ... 253 V AC/DC Max. current consumption: < 33 mA (24ÃVÃDC) Power consumption: < 0.8 W (24ÃVÃDC)
Input data	Measurement Configurable/programmable: Via DIP switches Input current range: 0 A AC ... 5 A AC (configurable) 0 A AC ... 12 A AC (configurable) Voltage input signal: Ã¢Ã¢°¤ 300 VÃAC Input impedance: < 50 mÃ© Overload capacity: 1 x I_N (continuous) Surge strength: 8 x I_N (1 s) Nominal frequency f_N: 50 Hz Frequency measuring range: 45 Hz ... 65 Hz Curve type: Sine
Output data	Signal: Current Configurable/programmable: Via DIP switches Non-load voltage: 15 V Current output signal: 0 mA ... 20 mA (configurable) 4 mA ... 20 mA (configurable) Max. current output signal: 25 mA Load/output load current output: < 500 Ã© (20ÃmA) Ripple: < 10 mV_PP (500ÃÃ©Ã/Ã20ÃmA) Status display: LED red (error), LED green (ready)
Connection data	Connection method: Screw connection Stripping length: 8 mm Screw thread: M3 Conductor cross section rigid: 0.2 mm² ... 2.5 mm² Conductor cross section flexible: 0.2 mm² ... 2.5 mm² Conductor cross section AWG: 24 ... 14
Interfaces	Data communication (bypass) Limit frequency (3 dB): approx. 3 Hz
Dimensions	Item dimensions Width: 22.5 mm Height: 104 mm Depth: 114.5 mm
Material specifications	Housing material: Polyamide PA non-reinforced
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 65°C -4°F ... 149°F Ambient temperature (storage/transport): -40°C ... 85°C (-40Ã°FÃ...Ã185Ã°F) Altitude: Ã¢Ã¢°¤ 2000 m Permissible humidity (operation): 10 % ... 95 % (non-condensing)
Approvals	CE Certificate: CE-compliant ATEX Identification: Ã¯Ã II 3 G Ex nA IIC T4 Gc X UKCAÃExÃ(UKEX) Identification: Ã¯Ã II 3 G Ex nA IIC T4 Gc Certificate: PxCIF21UKEX2810638X EACÃEx Identification: Ã¯ÃÃ¢ 2Ex nA IIC T4 Gc Certificate: BY/112 02.01 TP012 103.01 00078
EMC data	Noise immunity: EN 61000-6-2 Note: When being exposed to interference, there may be minimal deviations. Electromagnetic compatibility: Conformance with EMC directive Noise emission: EN 61000-6-4 Electrostatic discharge Standards/regulations: ENÃ61000-4-2 Electromagnetic HF field Standards/regulations: ENÃ61000-4-3 Electromagnetic HF fieldÃ¢Ã¢¬Ã¢¹ Comments: Criterion A Fast transients (burst) Standards/regulations: ENÃ61000-4-4 Fast transients (burst)Ã¢Ã¢¬Ã¢¹ Comments: Criterion B Surge current load (surge) Standards/regulations: ENÃ61000-4-5 Surge current load (surge)Ã¢Ã¢¬Ã¢¹ Comments: Criterion B Conducted interference Standards/regulations: ENÃ61000-4-6
Mounting	Mounting type: DIN rail mounting Mounting position: any
