2832221 PHOENIX CONTACT -

Product properties	Product type: Data cable preassembled Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45
Electrical properties	Contact resistance: Ã¢Ã¢°¤ 0.003 Ã© (IEC 60603-7) Nominal voltage U_N: 150 V_rms Nominal current I_N: 1.5 A Transmission speed: 1 Gbps
Mechanical properties	Mechanical data Insertion force per signal contact: 30.00 N Extraction force per signal contact: 50 N
Material specifications	Flammability rating according to UL 94: V0 Outer sheath, material: LSFROH
Dimensions	Width: 12.6 mm Height: 6.6 mm Length: 40.05 mm External dimensions External diameter max.: 6.2 mm
Connector	Connection 1 Type: Plug straight RJ45 Shielded: yes Insertion/withdrawal cycles: Ã¢Ã¢°¥ 750 750 Degree of protection: IP20 Number of positions: 8 Connection 2 Type: Plug straight RJ45
Cable/line	Cable length: 1.50 m External cable diameter: 5.50 mm Outer sheath, material: LSFROH Single wire, number of litz wires: 8 Single wire, material: Cu litz wire Single wire, cross section: 0.14 mm² Shielding: SF/UTP Smallest bending radius, fixed installation: 30 mm Halogen-free: according to IEC 60754-1 Concentration of fumes: in accordance with IEC 61034 Flame resistance: according to IEC 60332-3C
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -10°C ... 60°C
Standards and regulations	Flame resistance: according to IEC 60332-3C Concentration of fumes: in accordance with IEC 61034
