2904890 PHOENIX CONTACT -

PACT RCP-D95 - Coil

300 mm long Rogowski coil. The measuring coil diameter when installed is 95 mm. The Rogowski coil is used for AC current measurement for busbars and power lines.

Cod. Articolo: 2904890 copia - copy

Cod. Fornitore: 2904890 copia - copy

PHOENIX CONTACT

Product properties	Product type: Rogowski coil Insulation characteristics Pollution degree: 2
Electrical properties	Measuring coil Conductor structure signal line: 2x 0.22 mm (Signal (tinned)) 1x 0.22 mm (Shielding (tinned)) Insulation: double insulation Rated insulation voltage: 1000 VÃAC (rms CAT III) 600 VÃAC (rms CAT IV) Test voltage: 10.45 kV DC (60 s) Basic accuracy: <Ã± 0.2 % General Converter type: Rogowski coil
Input data	Frequency Designation: Measuring coil Frequency measuring range: 40 Hz ... 20000 Hz Position error: <Ã± 0.1 % (typical) Linearity error: < 0.1 % Current transformers Converter type: Rogowski coil
Output data	Signal Designation: Measuring coil Output signal (at 50 Hz): 100 mV (no load, at 1,000 A) Output voltage (in no-load operation): V_OUT = M * dI/dt Output voltage (sinusoidal, in no-load operation): 100 mV (V_OUT = 2 * ÃÃ¢¬ * M * f * I (M = 0.318 Ã¼H; example: At 50 Hz; I = 1,000 A))
Dimensions	Measuring coil Length: 300 mm Diameter: 8.3 mm Ã±0.2Ãmm Measuring coil when installed Diameter: 95 mm Signal line Length: 3 m
Material specifications	Coil material: Elastollan Housing material: PC
Environmental and real-life conditions	Ambient conditions Measuring coil degree of protection: IP67 (not assessed by UL) Ambient temperature (operation): -30°C ... 80°C (Measuring coil) Ambient temperature (storage/transport): -40°C ... 80°C (Measuring coil) Altitude: < 2000 m Permissible humidity (operation): 5 % ... 95 % (non-condensing)
Approvals	UKCA Certificate: UKCA-compliant CMIM Certificate: CMIM-compliant UL, USA/Canada Identification: UL 61010 Recognized Note: Measuring coil
Standards and regulations	Standards/regulations: IEC 61010-1 IEC 61010-2-032
