2906231 PHOENIX CONTACT -

PACT RCP-4000A-UIRO-D95 - Current transformer

Set consisting of a 4-way signal conditioner with screw connection technology and a Rogowski coil 300 mm in length/95 mm in diameter for AC current measurement on busbars and power lines.
The signal conditioner outputs 8 different standard signals on the output side and has one switching output.

Cod. Articolo: 2906231 copia - copy

Cod. Fornitore: 2906231 copia - copy

PHOENIX CONTACT

Product properties	Product type: Current transformer Insulation characteristics Overvoltage category: II Pollution degree: 2
Electrical properties	Electrical isolation: Reinforced insulation in accordance with IEC 61010-1 Typical measuring error: < 1 % Protective circuit: Surge protection; 33ÃV suppressor diode Step response (0Ã¢Ã¢¬Ã¢99%): 110 ms Rated insulation voltage: 300 V Measuring coil Conductor structure signal line: 2x 0.22 mm (Signal (tinned)) 1x 0.22 mm (Shielding (tinned)) Insulation: double insulation Rated insulation voltage: 1000 VÃAC (rms CAT III) 600 VÃAC (rms CAT IV) Test voltage: 10.45 kV DC (60 s) Basic accuracy: <Ã± 0.2 % Measuring transducers Maximum transmission error: Ã¢Ã¢°¤ 0.5 % (From the range end value) Frequency range: 16 Hz ... 1000 Hz Test voltage: 3 kV (50ÃHz, 1Ãmin.) General Can be calibrated: no Class: 1 Accuracy class: 1 Converter type: Rogowski coil and 4-way signal conditioner Supply: Measuring transducers Nominal supply voltage: 24 VÃDC Nominal supply voltage range: 9.6 VÃDC ... 30 VÃDC Power consumption: Ã¢Ã¢°¤ 1 W (at I_OUT = 20 mA, 9.6 V DC, 600 Ã© load)
Input data	Frequency Designation: Measuring coil Frequency measuring range: 40 Hz ... 20000 Hz Position error: <Ã± 0.1 % (typical) Linearity error: < 0.1 % Signal Input signal (at 50 Hz): 100 mV (1000 A) Curve type: Sine Input impedance: > 100 kÃ© Current transformers Configurable/programmable: Via DIP switches Rated frequency: Standard converter: 40 Hz ... 20000 Hz Primary rated current I_pn: 0 A AC ... 100 A AC 0 A AC ... 250 A AC 0 A AC ... 400 A AC 0 A AC ... 630 A AC 0 A AC ... 1000 A AC 0 A AC ... 1500 A AC 0 A AC ... 2000 A AC 0 A AC ... 4000 A AC Can be calibrated: no Class: 1 Accuracy class: 1 Converter type: Rogowski coil and 4-way signal conditioner
Output data	Switching: Transistor Number of outputs: 1 Contact switching type: 1 N/O contact Minimum switching voltage: 1 V Maximum switching voltage: 30 VÃDC Min. switching current: 100 ÃµA Max. switching current: 100 mA (at 30 V) Signal Designation: Measuring coil Output signal (at 50 Hz): 100 mV (no load, at 1,000 A) Output voltage (in no-load operation): V_OUT = M * dI/dt Output voltage (sinusoidal, in no-load operation): 100 mV (V_OUT = 2 * ÃÃ¢¬ * M * f * I (M = 0.318 Ã¼H; example: At 50 Hz; I = 1,000 A)) Accuracy class: 1 SignalÃ¢Ã¢¬Ã¢¹ Designation: Measuring transducer Configurable/programmable: Yes Voltage output signal: 0 V ... 10 V (via DIP switch) 2 V ... 10 V (via DIP switch) 0 V ... 5 V (via DIP switch) 1 V ... 5 V (via DIP switch) 0 V ... 10.5 V (can be set via software) Max. voltage output signal: Ã¯Ã¢» 12.3 V Current output signal: 0 mA ... 20 mA (via DIP switch) 4 mA ... 20 mA (via DIP switch) 0 mA ... 10 mA (via DIP switch) 2 mA ... 10 mA (via DIP switch) 0 mA ... 21 mA (can be set via software) Max. current output signal: 24.6 mA Load/output load voltage output: Ã¢Ã¢°¥ 10 kÃ© Load/output load current output: Ã¢Ã¢°¤ 600 Ã© (20ÃmA) Ripple: < 20 mV_PP
Connection data	Measuring transducer side Connection method: Screw connection Stripping length: 10 mm Screw thread: M3 Conductor cross section rigid: 0.2 mm² ... 1.5 mm² Conductor cross section flexible: 0.2 mm² ... 1.5 mm² Conductor cross section AWG: 26 ... 16 Tightening torque: 0.5 Nm ... 0.6 Nm
Dimensions	Item dimensions Width: 6.2 mm Height: 110.5 mm Depth: 120.5 mm Measuring coil Length: 300 mm Diameter: 8.3 mm Ã±0.2Ãmm Measuring coil when installed Diameter: 95 mm Signal line Length: 3 m Width: 6.2 mm Height: 110.5 mm Depth: 120.5 mm
Material specifications	Coil material: Elastollan Housing material: PC PBT
Environmental and real-life conditions	Ambient conditions Measuring coil degree of protection: IP67 (not assessed by UL) Measuring transducer degree of protection: IP20 Ambient temperature (operation): -30°C ... 80°C (Measuring coil) -40°C ... 70°C (Measuring transducer) Ambient temperature (storage/transport): -40°C ... 80°C (Measuring coil) -40°C ... 85°C (Measuring transducer) Altitude: < 2000 m Permissible humidity (operation): 5 % ... 95 % (non-condensing)
Approvals	CE Certificate: CE-compliant UKCA Certificate: UKCA-compliant CMIM Certificate: CMIM-compliant UL, USA/Canada Identification: UL 61010 Recognized Note: Measuring coil UL, USA/CanadaÃ¢Ã¢¬Ã¢¹ Identification: UL 508 Listed Note: Measuring transducer
EMC data	Noise immunity: EN 61000-6-2 Note: When being exposed to interference, there may be minimal deviations. Electromagnetic compatibility: Conformance with EMC directive Noise emission: EN 61000-6-4
Standards and regulations	Electrical isolation: Reinforced insulation in accordance with IEC 61010-1 Standards/regulations: IEC 61010-1 IEC 61010-2-032
Mounting	Mounting type: DIN rail mounting
