| Product properties | Product type: Timer relay Operating mode: 100% operating factor Mechanical service life: approx. 2x 107 cycles Insulation characteristics Insulation: Basic insulation Insulation characteristicsââ¬Ã¢¹ Insulation: Basic insulation Overvoltage category: III Pollution degree: 2 |
| Electrical properties | Service life electrical: approx. 2x 105 cycles at ohmic load, 1000 VA Nominal power consumption: 0.45 W (at 24 V DC) Rated insulation voltage: 300 VÃAC Rated surge voltage: 6 kV |
| Input data | Nominal power consumption: 0.45 W (at 24 V DC) Input voltage range: 24 VÃDC (19.2ÃVÃDC ... 30ÃVÃDC) Recovery time: 50 ms Setting range time: 0.1 s ... 300 min. (4 time end ranges) Setting accuracy: ââ°¤ 2.5 % (of scale end value) Repeat accuracy: ââ°¤ 0.5 % (of scale end value) Control Connection name: Non-floating, terminals A1-B1 Control pulse length: ââ°¥ 50 ms |
| Output data | Switching Contact switching type: 1 floating changeover contact Maximum switching voltage: 250 VÃAC Interrupting rating (ohmic load) max.: 1500 VA (6 A / 250 V AC) Output fuse: 6.3 A (fast-blow) |
| Connection data | Connection method: Screw connection Stripping length: 8 mm Conductor cross section rigid: 0.14 mm² ... 2.5 mm² Conductor cross section flexible: 0.14 mm² ... 2.5 mm² Conductor cross section AWG: 30 ... 12 Tightening torque: 0.6 Nm ... 0.8 Nm () 5 lbf-in. ... 7 lbf-in. |
| Signaling | Status display: Green LED (POWER) Yellow LED (relay active) |
| Dimensions | Width: 6.2 mm Height: 80 mm Depth: 86 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing insulation material: Polyamide PA, self-extinguishing |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 65°C Ambient temperature (storage/transport): -25°C ... 80°C Altitude: ââ°¤ 2000 m Permissible humidity (operation): 15 % ... 85 % |
| Approvals | CE Identification: CE-compliant UL, USA/Canada Identification: UL/C-UL Listed UL 508 |
| EMC data | Low Voltage Directive: Conformance with Low Voltage Directive Noise immunity: EN 61000-6-2 Electromagnetic compatibility: Conformance with EMC directive Noise emission: EN 61000-6-3 |
| Standards and regulations | Standards/regulations: IEC 61812-1 IEC 60947-5-1 |
| Mounting | Mounting type: DIN rail mounting Assembly instructions: on standard DIN rail NS 35 in accordance with EN 60715 Mounting position: any |
