3000571 PHOENIX CONTACT -

UK 16 N RD - Feed-through terminal block

Feed-through terminal block, nom. voltage: 800 V, nominal current: 76 A, number of connections: 2, connection method: Screw connection, Rated cross section: 16 mm², cross section: 2.5 mm²-25 mm², mounting type: NS 35/7,5, NS35/15, NS32, color: red

Cod. Articolo: 3000571 copia - copy

Cod. Fornitore: 3000571 copia - copy

PHOENIX CONTACT

Product properties	Product type: Feed-through terminal block Number of connections: 2 Number of rows: 1 Potentials: 1 Insulation characteristics Overvoltage category: III Degree of pollution: 3
Electrical properties	Rated surge voltage: 8 kV Maximum power dissipation for nominal condition: 2.43 W
Connection data	Number of connections per level: 2 Nominal cross section: 16 mm² Level 1 above 1 below 1 Screw thread: M4 Tightening torque: 1.5 ... 1.8 Nm Stripping length: 11 mm Internal cylindrical gage: B7 Connection in acc. with standard: IEC 60947-7-1 Conductor cross section rigid: 2.5 mm² ... 25 mm² Cross section AWG: 12 ... 4 (converted acc. to IEC) Conductor cross section flexible: 4 mm² ... 16 mm² Conductor cross section, flexible [AWG]: 10 ... 6 (converted acc. to IEC) Conductor cross-section flexible (ferrule without plastic sleeve): 1.5 mm² ... 16 mm² Flexible conductor cross section (ferrule with plastic sleeve): 1.5 mm² ... 16 mm² Cross-section with insertion bridge, rigid: 16 mm² Cross-section with insertion bridge, flexible: 16 mm² 2 conductors with same cross section, solid: 1.5 mm² ... 6 mm² 2 conductors with same cross section, flexible: 1.5 mm² ... 4 mm² 2 conductors with same cross section, flexible, with ferrule without plastic sleeve: 1.5 mm² ... 6 mm² 2 conductors with the same cross section, flexible, with TWIN ferrule with plastic sleeve: 0.75 mm² ... 10 mm² Nominal current: 76 A Maximum load current: 101 A (with 25 mm² conductor cross section) Nominal voltage: 800 V Nominal cross section: 16 mm²
Ex data	Rated data (ATEX/IECEx) Identification: Ã¯ÃÃIIÃ2ÃGDÃÃEx eb IIC Gb Operating temperature range: -60°C ... 110°C Ex-certified accessories: 3006027 D-UK 16 1205066 SZS 1,0X4,0 VDE 1201442 E/UK List of bridges: Fixed bridge / FBI 2-12 / 0200075 Fixed bridge / FBI 10-12 / 0203454 Bridge data: 66 A / 16 mm² Ex temperature increase: 40 K (75.1ÃA / 16Ãmm²) Rated voltage: 690 V for bridging with bridge: 690 V Rated insulation voltage: 630 V output: (Permanent) Ex level General Rated current: 68 A Maximum load current: 91 A Contact resistance: 0.17 mÃ© Ex connection data General Torque range: 1.5 Nm ... 1.8 Nm Nominal cross section: 16 mm² Rated cross section AWG: 6 Connection capacity rigid: 2.5 mm² ... 25 mm² Connection capacity AWG: 14 ... 4 12 ... 6 Connection capacity flexible: 4 mm² ... 16 mm² 2 conductors with same cross section, solid: 1.5 mm² ... 6 mm² 2 conductors with the same cross-section AWG rigid: 16 ... 10 2 conductors with same cross section, stranded: 1.5 mm² ... 4 mm² 2 conductors with the same cross-section AWG flexible: 16 ... 12
Dimensions	Width: 12.2 mm End cover width: 1.5 mm Height: 42.5 mm Depth on NSÃ32: 59 mm Depth on NSÃ35/7,5: 54 mm Depth on NSÃ35/15: 61.5 mm
Material specifications	Color: red Flammability rating according to UL 94: V0 Insulating material group: I Insulating material: PA
Mechanical properties	Mechanical data Open side panel: Yes
Environmental and real-life conditions	Ambient conditions Ambient temperature (storage/transport): -25°C ... 55°C (for a short time, not exceeding 24Ãh, -60Ã°C to +70Ã°C) Ambient temperature (assembly): -5°C ... 70°C Ambient temperature (actuation): -5°C ... 70°C Permissible humidity (storage/transport): 30 % ... 70 %
Standards and regulations	Connection in acc. with standard: IEC 60947-7-1
Mounting	Mounting type: NS 35/7,5 NSÃ35/15 NSÃ32
