3200807 PHOENIX CONTACT -

AI-TWIN 2X 0,75- 8 GY - Ferrule

Ferrules, for two 0.75 mm² conductors, sleeve length: 8 mm, with plastic collar, galvanically tin-plated, color: gray, color range according to NF C 63-023, CSA-certified

Cod. Articolo: 3200807 copia - copy

Cod. Fornitore: 3200807 copia - copy

PHOENIX CONTACT

Product properties	Product type: Cable end sleeve Conductor category: stranded conductors, class 2, 5, 6 / B, C, K, M
Connection data	Conductor connection Conductor cross section flexible max.: 0.75 mm² Conductor cross section AWG max.: 18 Stripping length: 12 mm
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/82c4f0cc34a6a144a6e5cc6b771b574d/-S204x204-FJPG Sleeve length: 8 mm Ferrule diameter: 1.7 mm Sleeve wall thickness: 0.15 mm Insulating collar thickness: 0.25 mm Inner dimensions of the insulating collar: 2.8 mm
Material specifications	Color: gray Material: CU-DHP Flammability rating according to UL 94: HB Coating: tin-plated (galvanic) Components: free from silicone and halogen
Mechanical properties	Technical data Sleeve length: 8 mm
Environmental and real-life conditions	Ambient conditions Permanent temperature: 105°C (-40Ã°C no load / 0Ã°C dynamic load) Short-term temperature: 120°C
Standards and regulations	Design according to standard: DINÃ46228-4, ULÃ486F-F
