3201398 PHOENIX CONTACT -

AI 1,5 - 8 BK-B - Ferrule

Ferrules, 1.5 mm², taped, sleeve length: 8 mm, with plastic collar, galvanically tin-plated, color: black, color range according to DIN 46228-4, CSA-certified

Cod. Articolo: 3201398 copia - copy

Cod. Fornitore: 3201398 copia - copy

PHOENIX CONTACT

Product properties	Product type: Cable end sleeve Conductor category: stranded conductors, class 2, 5, 6 / B, C, K, M
Connection data	Conductor connection Conductor cross section flexible max.: 1.5 mm² Conductor cross section AWG max.: 16 Stripping length: 11 mm
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/11dc1e287c07d142aca145bf2b10b3b2/-S204x204-FJPG Sleeve length: 8 mm Maximum stripping length: 11 mm Ferrule diameter: 1.7 mm Sleeve wall thickness: 0.15 mm Insulating collar thickness: 0.3 mm Inner dimensions of the insulating collar: 3.4 mm
Material specifications	Color: black Material: CU-DHP Flammability rating according to UL 94: HB Coating: tin-plated (galvanic) Components: free from silicone and halogen
Mechanical properties	Technical data Sleeve length: 8 mm
Environmental and real-life conditions	Ambient conditions Permanent temperature: 105°C (-40Ã°C no load / 0Ã°C dynamic load) Short-term temperature: 120°C
Standards and regulations	Design according to standard: DINÃ46228-4, ULÃ486F-E, NFCÃ63-023
