| Product properties | Product type: Connector |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/6b632624026a2f4abebd0cb782ac56a0/-S204x204-FJPG Width: 6.2 mm Length of the insulating material sleeve: 4.5 mm Maximum stripping length: 7 mm Distance from the center to the insulating material sleeve: 7.2 mm Min. material thickness: 0.75 mm Inner dimensions of the insulating collar: 1.9 mm Internal dimensions Internal diameter: 3.7 mm |
| Material specifications | Color: silver Material: Copper Coating: tin-plated Components: halogen-free |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): 110°C |
| Standards and regulations | Design according to standard: DINÃ46234 |
