Disponibile
| Product properties | Product type: Cable end sleeve |
| Connection data | Conductor connection Conductor cross section flexible max.: 0.34 mm² Conductor cross section AWG max.: 22 Stripping length: 10 mm |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/def7f15e9f11be4eb774878f9f0c6956/-S204x204-FJPG Sleeve length: 8 mm Maximum stripping length: 10 mm Ferrule diameter: 0.8 mm Sleeve wall thickness: 0.15 mm Insulating collar thickness: 0.25 mm Inner dimensions of the insulating collar: 2.2 mm |
| Material specifications | Color: turquoise Material: CU-DHP Flammability rating according to UL 94: HB Coating: tin-plated (galvanic) Components: free from silicone and halogen |
| Mechanical properties | Technical data Sleeve length: 8 mm |
| Environmental and real-life conditions | Ambient conditions Permanent temperature: 105°C (-40ðC no load / 0ðC dynamic load) Short-term temperature: 120°C |
| Standards and regulations | Design according to standard: Special color |
