3240663 PHOENIX CONTACT -

AI 0,5-8 WH-B 3000 - Ferrule

Ferrules, 0.5 mm², taped, sleeve length: 8 mm, with plastic collar, galvanically tin-plated, color: white, color range according to DIN 46228-4, CSA-certified

Cod. Articolo: 3240663 copia - copy

Cod. Fornitore: 3240663 copia - copy

PHOENIX CONTACT

Product properties	Product type: Cable end sleeve Conductor category: stranded conductors, class 2, 5, 6 / B, C, K, M
Connection data	Conductor connection Conductor cross section flexible max.: 0.5 mm² Conductor cross section AWG max.: 20 Stripping length: 11 mm
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/d8a7a66772f2c94d9d34b229995a8a79/-S204x204-FJPG Sleeve length: 8 mm Maximum stripping length: 11 mm Ferrule diameter: 1.1 mm Sleeve wall thickness: 0.15 mm Insulating collar thickness: 0.25 mm Inner dimensions of the insulating collar: 2.5 mm
Material specifications	Color: white Material: CU-DHP Flammability rating according to UL 94: HB Coating: tin-plated (galvanic) Components: free from silicone and halogen
Mechanical properties	Technical data Sleeve length: 8 mm
Environmental and real-life conditions	Ambient conditions Permanent temperature: 105°C (-40Ã°C no load / 0Ã°C dynamic load) Short-term temperature: 120°C
Standards and regulations	Design according to standard: DINÃ46228-4, ULÃ486F-E
