Non disponibile
| Product properties | Product type: Connector |
| Electrical properties | Fuse: yes |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/122067590e95884c8df3d76fd2018c11/-S204x204-FJPG Length of the insulating material sleeve: 11 mm Length contact range: 10.5 mm Min. material thickness: 0.75 mm Inner dimensions of the insulating collar: 4.1 mm Internal dimensions Internal diameter: 1.9 mm |
| Material specifications | Color: red Material: Copper Flammability rating according to UL 94: V2 Coating: tin-plated Insulating material: PA Components: halogen-free |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -20°C ... 105°C |
