3246857 PHOENIX CONTACT -

PS 6-CT-SD - Test disconnectors

Test disconnectors, contacts before the signal isolation, nom. voltage: 250 V, nominal current: 6 A, number of positions: 1, connection method: Screw connection, cross section:0.5 mm²- 2.5 mm², color: green

Cod. Articolo: 3246857 copia - copy

Cod. Fornitore: 3246857 copia - copy

PHOENIX CONTACT

Product properties	Product type: Test plug terminal block Number of positions: 1 Potentials: 1 Insulation characteristics Overvoltage category: III Degree of pollution: 3
Electrical properties	Rated surge voltage: 6 kV
Connection data	Nominal cross section: 2.5 mm² Rated cross section AWG: 14 Level 1 Screw thread: M3 Tightening torque: 0.5 ... 0.6 Nm Stripping length: 7 mm Connection in acc. with standard: IEC 60947-7-1 Conductor cross section rigid: 0.5 mm² ... 2.5 mm² Cross section AWG: 20 ... 14 (converted acc. to IEC) Conductor cross section flexible: 0.5 mm² ... 2.5 mm² Conductor cross section, flexible [AWG]: 20 ... 14 (converted acc. to IEC) Conductor cross-section flexible (ferrule without plastic sleeve): 0.5 mm² ... 1.5 mm² Flexible conductor cross section (ferrule with plastic sleeve): 0.5 mm² ... 1.5 mm² Nominal current: 6 A Maximum load current: 8 A Nominal voltage: 250 V
Dimensions	Width: 6.2 mm Height: 39.3 mm Depth: 73.1 mm Length: 39.3 mm
Material specifications	Color: green Flammability rating according to UL 94: V0 Insulating material group: I Insulating material: PA Static insulating material application in cold: -60°C Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)): 125°C Relative insulation material temperature index (Elec., UL 746 B): 130°C Fire protection for rail vehicles (DIN EN 45545-2) R22: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R23: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R24: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R26: HL 1 - HL 3 Calorimetric heat release NFPA 130 (ASTM E 1354): 27,5 MJ/kg Surface flammability NFPA 130 (ASTM E 162): passed Specific optical density of smoke NFPA 130 (ASTM E 662): passed Smoke gas toxicity NFPA 130 (SMP 800C): passed
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -60°C ... 105°C (max. short-term operating temperature RTI Elec.) Ambient temperature (storage/transport): -25°C ... 60°C (for a short time, not exceeding 24Ãh, -60Ã°C to +70Ã°C) Ambient temperature (assembly): -5°C ... 70°C Ambient temperature (actuation): -5°C ... 70°C Permissible humidity (storage/transport): 30 % ... 70 %
Standards and regulations	Connection in acc. with standard: IEC 60947-7-1
