3270620 PHOENIX CONTACT -

LPS-16/E - Service connector

Service connector, nom. voltage: 800 V, nominal current: 24 A, connection method: Push-in connection, Rated cross section: 2.5 mm², cross section: 0.14 mm²- 4 mm², color: red

Cod. Articolo: 3270620 copia - copy

Cod. Fornitore: 3270620 copia - copy

PHOENIX CONTACT

Product properties	Product type: Test plug terminal block Data management status Article revision: 01
Connection data	Stripping length: 10 mm 8 mm ... 10 mm Conductor cross section rigid: 0.14 mm² ... 4 mm² Cross section AWG: 26 ... 12 (converted acc. to IEC) Conductor cross section flexible: 0.14 mm² ... 4 mm² Conductor cross section, flexible [AWG]: 26 ... 12 (converted acc. to IEC) Conductor cross-section flexible (ferrule without plastic sleeve): 0.14 mm² ... 2.5 mm² Flexible conductor cross section (ferrule with plastic sleeve): 0.14 mm² ... 2.5 mm² Nominal current: 24 A Nominal voltage: 800 V Nominal cross section: 2.5 mm² Connection cross sections directly pluggable Conductor cross section rigid: 0.5 mm² ... 2.5 mm² Conductor cross section, rigid [AWG]: 20 ... 14 (converted acc. to IEC) Conductor cross-section flexible (ferrule without plastic sleeve): 0.5 mm² ... 2.5 mm² Flexible conductor cross section (ferrule with plastic sleeve): 0.5 mm² ... 2.5 mm²
Dimensions	Width: 16 mm Height: 18.3 mm Depth: 70.1 mm
Material specifications	Color: red (RAL 3001) Material: PA Flammability rating according to UL 94: V0
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -60 °C (max. operating temperature see derating curve)
