| Product properties | Product type: Current transformer Insulation characteristics Insulation: double insulation Insulation characteristicsââ¬Ã¢¹ Insulation: double insulation Overvoltage category: III (1000ÃV, to neutral conductor) IV (600ÃV, to neutral conductor) Pollution degree: 2 |
| Electrical properties | Electrical isolation: Reinforced insulation in accordance with IEC 61010-1 Typical measuring error: < 1 % Protective circuit: Surge protection; 33ÃV suppressor diode Temperature coefficients: 0.005 %/K (+10ðCÃ...Ã+70ðC, both components have the same ambient temperature) 0.07 %/K (-20ðCÃ...Ã+10ðC, both components have the same ambient temperature) Measuring coil Conductor structure signal line: 2x 0.22 mm (Signal (tinned)) 1x 0.22 mm (Shielding (tinned)) Insulation: double insulation Rated insulation voltage: 1000 VÃAC (rms CAT III) 600 VÃAC (rms CAT IV) Test voltage: 10.45 kV DC (60 s) Basic accuracy: <ñ 0.2 % Measuring transducers Linearity error: < 0.5 % (From the range end value) Maximum transmission error: ââ°¤ 0.5 % (From the range end value) Frequency range: 45 Hz ... 65 Hz Max. detectable harmonics: < 2 kHz Current consumption: < 190 mA (at 19.2 V) Test voltage: 1.5 kV AC (Supply/input and output: 50 Hz, 1 min) General Can be calibrated: no Class: 1 Accuracy class: 1 Converter type: Rogowski coil and 1ÃA measuring transducer Supply: Measuring transducers Nominal supply voltage: 24 VÃDC -20Ã%Ã...Ã+25Ã% Nominal supply voltage range: 19.2 VÃDC ... 30 VÃDC Max. current consumption: 190 mA Power consumption: 4 W |
| Input data | Frequency Designation: Measuring coil Frequency measuring range: 40 Hz ... 20000 Hz Position error: <ñ 0.1 % (typical) Linearity error: < 0.1 % Signal Input signal (at 50 Hz): 100 mV (1000 A) Curve type: Sine Input impedance: 27 ké (smallest measuring range) Current transformers Configurable/programmable: Via DIP switches Rated power: 1.5 VA Primary rated current Ipn: 0 A AC ... 100 A AC 0 A AC ... 250 A AC 0 A AC ... 400 A AC 0 A AC ... 630 A AC 0 A AC ... 1000 A AC 0 A AC ... 1500 A AC 0 A AC ... 2000 A AC 0 A AC ... 4000 A AC Phase angle: < 1° Can be calibrated: no Class: 1 Accuracy class: 1 Converter type: Rogowski coil and 1ÃA measuring transducer |
| Output data | Signal Designation: Measuring coil Output signal (at 50 Hz): 100 mV (no load, at 1,000 A) Output voltage (in no-load operation): VOUT = M * dI/dt Output voltage (sinusoidal, in no-load operation): 100 mV (VOUT = 2 * Ã⬠* M * f * I (M = 0.318 üH; example: At 50 Hz; I = 1,000 A)) Accuracy class: < 1 Signalââ¬Ã¢¹ Designation: Measuring transducer Current output signal: 0 A AC ... 1 A AC Rated power: 1.5 VA Load: 0 é ... 1.5 é Max. distances for copper cables at PN max: 32 m (0.75Ãmm² (AWG 20)) 64 m (1.5Ãmm² (AWG 16)) 107 m (2.5Ãmm² (AWG 14)) |
| Connection data | Measuring transducer side Connection method: Screw connection Stripping length: 7 mm Screw thread: M3 Conductor cross section rigid: 0.2 mm² ... 2.5 mm² Conductor cross section flexible: 0.2 mm² ... 2.5 mm² Conductor cross section AWG: 24 ... 14 Tightening torque: 0.5 Nm ... 0.6 Nm |
| Signaling | Operating voltage display: Green LED |
| Dimensions | Item dimensions Width: 22.5 mm Height: 85 mm Depth: 70.4 mm Measuring coil Length: 450 mm Diameter: 8.3 mm ñ0.2Ãmm Measuring coil when installed Diameter: 140 mm Signal line Length: 10 m Width: 22.5 mm Height: 85 mm Depth: 70.4 mm |
| Material specifications | Coil material: Elastollan Housing material: PC Polyamide |
| Environmental and real-life conditions | Ambient conditions Measuring coil degree of protection: IP67 (not assessed by UL) Measuring transducer degree of protection: IP20 Ambient temperature (operation): -30°C ... 80°C (Measuring coil) -20°C ... 70°C (Measuring transducer) Ambient temperature (storage/transport): -40°C ... 80°C (Measuring coil) -25°C ... 85°C (Measuring transducer) Altitude: < 2000 m Permissible humidity (operation): 5 % ... 95 % (non-condensing) |
| Approvals | CE Certificate: CE-compliant UKCA Certificate: UKCA-compliant CMIM Certificate: CMIM-compliant UL, USA/Canada Identification: UL 61010 Recognized Note: Measuring coil UL, USA/Canadaââ¬Ã¢¹ Identification: UL 508 Listed Note: Measuring transducer |
| EMC data | Noise immunity: ENÃ61000-6-3 Electromagnetic compatibility: Conformance with EMC directive Noise emission: EN 61000-6-4 |
| Standards and regulations | Electrical isolation: Reinforced insulation in accordance with IEC 61010-1 Standards/regulations: IEC 61010-1 IEC 61010-2-032 |
| Mounting | Mounting type: DIN rail mounting |
