| Notes | General: NOTE: Observe the permissible bending radii when laying conductors, since the degree of protection may be put in jeopardy if the bending forces are too high. Alleviate mechanical loads upstream of the connector, e.g.Ãby using cable ties. |
| Product properties | Product type: Installation connector Product family: IPD Number of positions: 3 Connection profile: 2+PE Position marking: L, N, PE Number of connections per position: 1 Series: IPD Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Electrical properties | Rated surge voltage (III/3): 6 kV Rated current: 20 A Rated voltage (III/3): 500 V Nominal voltage UN: 500 VÃAC 500 VÃDC Nominal current IN: 20 A |
| Connection data | Connection technology Connection technology: Push-lock connection Conductor connection Conductor cross section flexibel: 0.5 mm² ... 2.5 mm² Conductor cross section solid: 0.5 mm² ... 2.5 mm² Connection cross section AWG: 20 ... 14 |
| Dimensions | Width: 26.5 mm Length: 86 mm |
| Material specifications | Material: PA Cu Ni/Ag/Sn |
| Cable/line | External cable diameter (): 6 mm ... 9 mm 8 mm ... 13 mm Position marking: L, N, PE |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 IP68 (2Ãm / 24Ãh) IP69K Ambient temperature (operation): -30°C ... 100°C Temperature when conductor connected: -5°C ... 50°C Ambient temperature (storage/transport): -30°C ... 100°C Resistance to UV radiation: yes |
| Standards and regulations | Resistance to UV radiation: yes |
| Mounting | Connection method: Push-lock connection |
