| Product properties | Product type: Data cable preassembled Cable outlet: straight Data management status Article revision: 02 Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 72 V Rated current: 1.75 A Insulation resistance: > 1 Té Contact resistance: < 20 mé Transmission characteristics (category): CAT5 Transmission speed: 100 Mbps |
| Mechanical properties | Mechanical data Insertion force per signal contact: 50.00 N Extraction force per signal contact: 30 N |
| Material specifications | Flammability rating according to UL 94: V2 Housing material: PP Contact material: CuSn6 Contact surface material: Ni/Au Contact carrier material: PC |
| Dimensions | Width: 34.7 mm Height: 14.8 mm Length: 35.3 mm |
| Connection data | Connection technology Connection method: Pierce connection Conductor connection Connection method: Pierce connection |
| Connector | Connection 1 Type: Plug straight RJ45 Shielded: yes Handle color: black Insertion/withdrawal cycles: ââ°¥ 750 Degree of protection: IP20 Connection 2 Type: Plug Left RJ45 Shielded: yes Handle color: black Insertion/withdrawal cycles: ââ°¥ 750 Degree of protection: IP20 |
| Cable/line | Cable length: 2.00 m PROFINET PVC stranded CAT5 [93B] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9062/full/b1500?format=jpg Shielded: yes UL AWM Style: 21694 Cable weight: 67 kg/km Cable type: PROFINET PVC stranded CAT5 Short symbol: 2YY(ST)CY Cable type (abbreviation): 93B Signal type/category: PROFINET CAT5 (IEC 11801), 100 Mbps EtherCATî CAT5 (IEC 11801), 100 Mbps Cable structure: 1x4xAWG22/7, SF/TQ External cable diameter: 6.50 mm ñ0.2 mm Outer sheath, material: PVC External sheath, color: green RAL 6018 Thickness, outer sheath: approx. 0.90 mm Material, inner sheath: PVC Conductor material: Tin-plated Cu litz wires Conductor structure signal line: 7x 0.25 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² Material wire insulation: PE Wire diameter incl. insulation: 1.55 mm Single wire, color: white, yellow, blue, orange Overall twist: Star quad Shielding: Aluminum-coated foil, tinned copper braided shield Optical shield covering: 85 % Nominal voltage, cable: 600 V Test voltage Core/Core: 2000 V (50 Hz, 1 min.) Test voltage Core/Shield: 2000.00 V (50 Hz, 1 min.) Cable insulation resistance: ââ°¥ 500 Mé*km Coupling resistance: ââ°¤ 20.00 mé/m (at 10 MHz) Wave impedance: 100 é ñ15 é (at 100 MHz) Loop resistance: ââ°¤ 120.00 é/km Signal runtime: 5.3 ns/m Signal speed: 0.66 c Minimum bending radius, fixed installation: 3 x D Minimum bending radius, flexible installation: 7 x D Near end crosstalk attenuation (NEXT): 80 dB (with 1 MHz) 76 dB (at 4 Ãà Hz) 70 dB (at 10 MHz) 65 dB (at 16 MHz) 63 dB (at 20 Ãà Hz) 60 dB (at 31.25 Ãà Hz) 55 dB (at 62.5 Ãà Hz) 50 dB (at 100 MHz) Resistance to oil: Resistant to oil to a limited extent Flame resistance: according to UL 1685 (CSA FT 4) Other resistance: UV resistant (according to UL 1581, Section 1200) Ambient temperature (operation): -40 °C ... 70 °C (Cable, flexible installation) -40 °C ... 70 °C (cable, fixed installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40 °C ... 85 °C (RJ45 connector) |
| Standards and regulations | Standards/specifications: IEC 60603-7 |
