| Product properties | Type: RJ45 Socket Product type: Data connector (device side) Type of packaging: Tape and Reel [W] tape width: 44.00 mm [A] coil diameter: 330.00 mm [W2] coil overall dimension: 49.00 mm Housing shield springs: No Connection profile: RJ45 Number of slots: 1 Shielded: yes Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 72 VÃDC Rated surge voltage: 1.5 kV DC 1 kV DC Rated surge voltage (III/3): 1.5 kV Rated current: 1.5 A Frequency range: 10 Hz ... 500 Hz Insulation resistance: > 500 Mé Test voltage: 1 kV DC Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Transmission medium: Copper Transmission speed: 10 Gbps Power transmission: PoE++ |
| Connection data | Connection technology Connection method: SMD reflow |
| Dimensions | Width: 18.8 mm Height: 13.5 mm Length: 15.75 mm Installed height: 13.50 mm Orientation to: 90.00° |
| Material specifications | Material: Au (0.152Ãõm / 6 õ") Ni (1.27Ãõm / 50 õ") Ni (1.27Ãõm / 50 õ") Copper alloy Flammability rating according to UL 94: V0 Housing surface material: Nickel Contact material: Phosphor bronze Contact surface material: Gold Contact carrier material: PA 9T GF Housing material: Metal |
| Cable/line | Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Halogen-free: no Flame resistance: ULÃ94 V0 |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 750 Insertion force per signal contact: < 20.00 N Extraction force per signal contact: < 20 N |
| Environmental and real-life conditions | Test specification Frequency: 10-500 Hz Sweep speed: 1Ãoctave/min Amplitude: 0.35 mm Acceleration: 50 m/s² Test duration: 20 s Test specificationââ¬Ã¢¹ Specification: IEC60068-2-27 Acceleration: 295 m/s² Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 85°C Ambient temperature (storage/transport): -40°C ... 85°C |
| Standards and regulations | Flame resistance: ULÃ94 V0 |
| Mounting | Mounting type: SMD soldering Connection method: SMD reflow Processing notes Moisture Sensitive Level: MSL 1 Classification temperature Tc: 260°C Solder cycles in the reflow: 3 |
